ELORA UPHOLSTERED BED
ASSEMBLY INSTRUCTIONS
BOX#1
A. HEADBOARD
BOX#2
B.
FOOTBOARD
B
BOX#3
C. SIDE RAIL
D. SLAT
E. CENTER SLAT SUPPORT
F. SIDE RAIL SLAT CLIP
G. CENTER SUPPORT SLAT CLIP
H. SLAT SUPPORT LEG
C
E
G
FULL/QUEEN
1 PC
A
1 PC
2 PCS
26
PCS
1
PC
26
PCS
13
PCS
2
PCS
D
F
H
HARDWARE KIT PACKED IN BOX #2
1
ALLEN
BOLT(5/16"x1-1/4")
2
ALLEN
BOLT(5/16"x2-1/2")
3
FLAT WASHER(5/16")
LOCK WASHER(5/16")
4
ALLEN KEY 5/16")
(
5
FULLY ASSEMBLED
4 PCS
2 PCS
6 PCS
6 PCS
1 PC
x2
x2
x2
00:30
00:30
00:30
