Configuring Basic Networking Using the OSD

This procedure requires a hardware connection already made between the
KVM/net's KVM management port and a local monitor, keyboard, and
mouse, as described under "To Connect to the User 1 Management Port" on
page 83. After the KVM/net and monitor are powered on, the OSD login
screen appears.
The following table shows how to perform common actions described in the
following procedures when working with the OSD.
Table 2-2: OSD Equivalents for Common Actions
Action
Press OK.
Enter <any value>.
Save changes.
Select <an option>.
Go to a specific screen, as in:
"Go to 'Configure > Users and
Groups > Local Users > Change
Password'."
Exit the OSD.
Installation
Performing Basic Network Configuration
OSD Equivalent
Tab to the OK button and press the Enter key on
your keyboard.
Type the value in the appropriate field and press
the Enter key.
Tab to the Save button and press the Enter key.
Press an arrow key to navigate. Select the menu
option and then press the Enter key.
From the Main menu, select the first option
shown in the menu path; "Configure" in the
example. On the next menu, select the next option
shown after the > (right angle bracket); "Users
and Groups" in the example. Repeat until you
select the last option in the menu path.
Click the X box on the upper right of the viewer.
If you are on the Main Menu, you can select Exit.
89
