HUAWEI B628-265 LTE CPE
V100R001
Product Description
Issue
01
Date
2020-05-09
Huawei Device Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B628-265 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Huawei B628-265

Summary of Contents for Huawei B628-265

  • Page 1 HUAWEI B628-265 LTE CPE V100R001 Product Description Issue Date 2020-05-09 Huawei Device Co., Ltd.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
  • Page 3 The document is an invitation to offer but not an offer. It is intended to describe the general features and functions of a product. The features and functions of certain products may vary with the requirements of customers. History Issue Date Details 2020-05-09 Initial official release. Huawei Proprietary and Confidential Issue 01 (2020-05-09) Copyright © Huawei Device Co., Ltd.
  • Page 4 High Speed Packet Access HSPA+ High Speed Packet Access Evolution IEEE Institute of Electrical and Electronics Engineers Internet Protocol IPSec Internet Protocol Security IPv4 Internet Protocol version 4 Huawei Proprietary and Confidential Issue 01 (2020-05-09) Copyright © Huawei Device Co., Ltd.
  • Page 5 SAMBA System for Advanced Mobile Broadband Applications Secondary Component Carrier Service Control Point SDRAM Synchronous Dynamic Random Access Memory Session Description Protocol Serving Gateway Session Initiation Protocol Huawei Proprietary and Confidential Issue 01 (2020-05-09) Copyright © Huawei Device Co., Ltd.
  • Page 6 Wireless Encryption Protocol Wi-Fi Wireless Fidelity Wi-Fi Multimedia WPA/WPA2-PSK Wi-Fi Protected Access/Wi-Fi Protected Access II - Pre-Shared Key WPA2-PSK Wi-Fi Protected Access II - Pre-Shared Key Wi-Fi Protected Setup Huawei Proprietary and Confidential Issue 01 (2020-05-09) Copyright © Huawei Device Co., Ltd.

  • Page 7: Table Of Contents

    3.9 5GHz Preferred ................................18 3.10 HiLink ..................................18 3.11 Customer management .............................. 19 3.11.1 WebUI ..................................19 3.11.2 HUAWEI AI Life APP ............................19 3.12 Operator maintenance (optional) ..........................19 Huawei Proprietary and Confidential Issue 01 (2020-05-09) Copyright © Huawei Device Co., Ltd.
  • Page 8 5.1.1 Standards and Communication Protocols of the Product ..................22 5.1.2 Standards and Communication Protocols of the Wireless Uu Interface ..............22 6 Packing List ..........................23 Huawei Proprietary and Confidential Issue 01 (2020-05-09) Copyright © Huawei Device Co., Ltd.

  • Page 9: Product Overview

    Product Description 1 Product Overview Product Overview The HUAWEI LTE CPE B628-265 is a Long Term Evolution (LTE) wireless gateway for multiple users in household or small office environments. It enables users to access the Internet. The B628-265 supports 3GPP Release 11 with LTE CAT 12. The supported service functions are as follows: ...
  • Page 10 HUAWEI B628-265 LTE CPE Product Description 1 Product Overview Figure 1-1 B628-265 appearance Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright © Huawei Device Co., Ltd.

  • Page 11: Technical Specifications

    HUAWEI B628-265 LTE CPE Product Description 2 Technical Specifications Technical Specifications 2.1 Hardware Specifications Table 2-1 Technical specifications of the B628-265 main unit Item Description Technical 3GPP Release 11 standard IEEE 802.3/802.3u Wi-Fi IEEE 802.11b/g/n/a/ac Working B1/3/7/8/20/28/32/38/41 band/frequency UMTS B1/8 Wi-Fi 2.402 GHz-2.482 GHz, 5.17GHz-5.33GHz &...
  • Page 12 Flash quickly: HiLink pairing is in progress/WPS connection is in progress. Off: Wi-Fi is disabled.  The indicator starts to flash slowly only when B628-265 detects a new HiLink device.  HiLink devices include Honor routers, Honor set-up boxes, Honor handsets/ HUAWEI handsets (EMUI 5.0 and later), and more.
  • Page 13 -97.1 -95.8 -103.1 -100.8 -98.5 -96.5 -94.8 -100.9 -99.3 -97.7 -96.5 -100.5 -98.1 -95.9 -94.8 -100.1 -97.4 -95.9 -94.6 UMTS  B1: -108 dBm  B8: -110.6 dBm Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright © Huawei Device Co., Ltd.
  • Page 14 Storage temperature: -20° C to +70° C 5% – 95% (non-condensing) Humidity Certification/Co CE certification mpliance RoHS REACH WEEE Wi-Fi certification Table 2-2 Frequency band combination of the B628-265 Item Description Frequency band 2CA(DL) combination MIMO CA_1C CA_3C CA_7C CA_38C...

  • Page 15: Antenna Specifications

    B20: UL 832–862 MHz DL 791–821 MHz  B28: UL 703–748 MHz DL 758–803 MHz  B32: / DL 1452–1496 MHz  B38: UL 2570–2620MHz DL 2570–2620 MHz Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright © Huawei Device Co., Ltd.
  • Page 16  B1: -2.2 dB  B8: -4.1 dB Main antenna gain  B8/20/28/38: 2~3 dBi  B1/3/7/41: 3~4 dBi UMTS  B1: 3~4 dBi  B8: 2~3 dBi Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright © Huawei Device Co., Ltd.

  • Page 17: Build-In Wi-Fi Antenna

    Table 2-5 Wi-Fi 5 GHz antenna specifications Item Description Frequency 5.17GHz~5.33GHz & 5.49GHz~5.71GHz 50 Ω Input impedance Standing wave ratio < 2 Efficiency -3 dB Gain 4 dBi Polarization Linear polarization Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright © Huawei Device Co., Ltd.

  • Page 18: Software Specifications

    NAT-base service (such as port forwarding and port triggering) is not available VPN pass-through  VPN client Support L2TP VPN client  Support PPTP VPN client  Writing/sending/receiving  Writing/sending/receiving extra-long messages Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright © Huawei Device Co., Ltd.
  • Page 19 Three-way conference  Originating Identification Presentation/Restriction  Outgoing Communication Barring  VoLTE Supports AMR-NB codec  (Optional) Supports AMR-WB codec Supports SRVCC to UMTS Supports in-band/out-band (RFC2833) DTMF Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright © Huawei Device Co., Ltd.
  • Page 20 Supports the MAC address authentication blacklist  Supports a maximum of 32 MAC address entries  Supports inquiry of STA status  Supports a maximum of 64 connected stations Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright © Huawei Device Co., Ltd.
  • Page 21  Safari 10.0 with latest updates (Mac OS) Your computer's hardware system should meet or exceed the recommended system requirements for the installed OS version Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright © Huawei Device Co., Ltd.

  • Page 22: Services And Applications

    3.1 Data Services The B628-265 can access the Internet through mobile networks and Ethernet networks. By connecting to the B628-265 using Wi-Fi or a network cable, users can obtain access to high-speed Internet services and establish a local area network (LAN).

  • Page 23: Accessing The Internet Through An Ethernet Network

    Product Description 3 Services and Applications 3.1.2 Accessing the Internet through an Ethernet Network The B628-265's LAN/WAN port can be connected to a wall-mounted Ethernet port using a network cable. Figure 3-2 Accessing the Internet through an Ethernet network 3.2 Voice Services The B628-265 provides one telephone port that can be connected to telephones for calling.

  • Page 24: Firewall Service

    3 Services and Applications 3.4.1 Firewall Service The B628-265 supports the enabling or disabling of a firewall on the network connection, which protects the device and network from attacks by hackers on the Internet and controls access to the Internet.

  • Page 25: Ip Pass-Through (Optional)

    3.7.1 IPv4v6 Dual Stack CPE provides dual stack function. 3.7.2 IPv6 Only (CLAT) (optional) The LTE CPE supports IPv6 only with the transition solution CLAT for IPv4 device. Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright © Huawei Device Co., Ltd.

  • Page 26: Multi-Apn (Optional)

    Priority usage of 5 GHz Wi-Fi band over 2.4 GHz band when signal strength is equal to increase connection speeds. 3.10 HiLink  Supports HiLink routers to connect to B628-265 through the H button to create an expanded network.  Supports quick connection between a HiLink device (such as Honor set-up boxes, Honor handsets and HUAWEI handsets running on EMUI 5.0 and later) and B628-265 through...

  • Page 27: Customer Management

    The B628-265 supports Operator maintenance through the TR-069. Operator remote manages the CPE software update/parameters configuration via TR-069. 3.13 HOTA The B628-265 supports the HOTA feature, which allows users to remotely update the device firmware through the HOTA server. Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright ©...

  • Page 28: System Structure And Scenario Constraints

    Ethernet access function: The B628-265 adopts the Ethernet access technology at the WAN side.  LTE access function: The B628-265 adopts the LTE access technology at the WAN side.  LAN access function: One 10/100/1000 Mbps high-speed Ethernet ports are provided at the LAN side.

  • Page 29: Scenario Constraints

    (SOHOs). The B628-265 is not an enterprise-grade product. It cannot be used by medium- or large-sized enterprises or in scenarios with high network reliability requirements, such as banks, securities agencies, traffic control, and communications device backhaul.

  • Page 30: Technical References

    RFC792, RFC950, RFC1256 RFC793 RFC768 DHCP RFC1531, RFC1533 RFC1631, RFC2663, RFC3022, RFC3027 VoIP RFC3261,RFC2327,RFC1889,RFC1890,RFC3550 5.1.2 Standards and Communication Protocols of the Wireless Uu Interface This device supports 3GPP Release 11. Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright © Huawei Device Co., Ltd.

  • Page 31: Packing List

    Wireless Gateway Standard Power supply adapter Standard Quick Start Standard Ethernet cable Optional Warranty card Optional Phone cable Optional The HUAWEI B628-265 wireless gateway has an optional external antenna. Issue01 (2020-05-09) Huawei Proprietary and Confidential Copyright © Huawei Device Co., Ltd.
