4-1/2" ANGLE GRINDER
PRODUCT SPECIFICATIONS
120 volts,60Hz
9.0 Amps
12,000/min
4-1/2 inch (115mm)
5/8"
241-0979
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 241-0979 and is the answer not in the manual?

Questions and answers

Summary of Contents for Performax 241-0979

  • Page 1 4-1/2" ANGLE GRINDER 241-0979 Owner's Manual PRODUCT SPECIFICATIONS Voltage: 120 volts,60Hz Current rating: 9.0 Amps No Load Speed : 12,000/min Grinding wheel: 4-1/2 inch (115mm) Spindle thread: 5/8" Double insulated Need Assistance ? Call us on our toll free customer support line : 1-866-915-8626 •...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS General Safety Rules..................Page 2 Specific Safety Rules................... Page 4 Symbols....................... Page 5 Electrical...................... Page 6 Features....................... Page 8 Assembly...................... Page 8 Operating procedures.................. Page 9 Maintenance....................Page 11 Parts list....................... Page 11 Schematic drawing..................Page 12 Warranty.......................
  • Page 3 plugs with grounded power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. b) Avoid body contact with grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is grounded. c) Do not expose power tools to rain or wet conditions.
  • Page 4: Specific Safety Rules

    e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools. f) Keep cutting tools sharp and clean.
  • Page 5: Symbols

    • Check for alignment of moving parts, binding of moving parts, breakage of parts, mounting, and any other conditions that may affect its operation. A guard or other part that is damaged should be prop- erly repaired or replaced by an authorized service center. Following this rule will reduce the risk of •...
  • Page 6: Electrical

    CAUTION : Indicates a potentially hazardous situation, which, if not avoided, may result in minor or moderate injury. CAUTION : (Without Safety Alert Symbol) Indicates a situation that may result in property damage. Some of the following symbols may be used on this product. Please study them and learn their meaning.
  • Page 7 WARNING : The double insulated system is intended to protect the user from shock resulting from a break in the tool’s internal wiring. Observe all normal safety precautions to avoid electrical shock. NOTE : Servicing of a tool with double insulation requires extreme care and knowledge of the system and should be performed only by a qualified service technician.
  • Page 8: Features

    WARNING : Check extension cords before each use. If damaged, replace immediately. Never use tool with a damaged cord since touching the damaged area could cause electrical shock resulting in serious injury. FEATURES FUNCTIONAL DESCRIPTION Before attempting to use this product, familiarize yourself with all operating features and safety rules. 1.
  • Page 9: Operating Procedures

    OPERATING PROCEDURES Grinding and Cut-off Wheels This angle grinder is designed to accept only abrasive discs with a 7/8” bore. Check to ensure that any discs used on this machine are rated for the 11,000 rpm speed of this grinder. Check also for any damage to an abrasive disc before installing.
  • Page 10 Remove a Disc Unscrew(counterclockwise) the outer flange with ■ the provided spanner. (See Figure D3) Remove the disc from the tool spindle and inner flange ■ Install a disc Place the inner flange onto the spindle.(See Figure D1) ■ Place the disc on the tool spindle and inner flange. ■...
  • Page 11: Maintenance

    MAINTENANCE Check the brushes occasionally (after about 60 hours of use) and replace if worn. Unplug the tool.  Unscrew the round brush covers on each side of the body and pull the brushes out to check or replace them. If you replace the brushes, run the tool without load for 15 minutes to seat the brushes properly.
  • Page 12: Schematic Drawing

    SCHEMATIC DRAWING...
  • Page 13: Warranty

    At its discretion, PERFORMAX agrees to have the tool or any defective part(s) repaired or replaced with the same or similar PERFORMAX product or part free of charge, within the stated warranty period, when returned by the original purchaser with original sales receipt.

Table of Contents
