H5020
GoSmart PIR Motion Detector Zigbee IP-2210Z
Table of Contents
Safety instructions and warnings ........................................................................................... 2
Contents of the package ........................................................................................................ 3
Technical Specifications .......................................................................................................... 3
Description of the device ....................................................................................................... 4
Installation and assembly ....................................................................................................... 5
Controls and functions ......................................................................................................... 12
Troubleshooting FAQ ........................................................................................................... 15
1
Advertisement
Table of Contents
Related Manuals for GoSmart H5020
Summary of Contents for GoSmart H5020
-
Page 1: Table Of Contents
H5020 GoSmart PIR Motion Detector Zigbee IP-2210Z Table of Contents Safety instructions and warnings ................... 2 Contents of the package ......................3 Technical Specifications ......................3 Description of the device ....................... 4 Installation and assembly ....................... 5 Controls and functions ......................12... -
Page 2: Safety Instructions And Warnings
Do not use water or chemicals to clean dirt from the outside of the device. Always use a dry cloth to prevent mechanical damage and electric shock. EMOS spol. s r.o. declares that the product H5020 complies with the essential requirements and other relevant provisions of the directives. The equipment can be operated freely in the EU. -
Page 3: Contents Of The Package
Dimensions: 48.4 × 53.4 mm PIR distance: 8 m PIR angle: 90° APP: EMOS GoSmart for Android and iOS Connectivity: 2.4 GHz Zigbee 3.0 (2 405-2 480 MHz) Notice Sensors must be connected to the ZigBee gateway. The ZigBee gateway itself must be connected to a 2.4 GHz Wi-... -
Page 4: Description Of The Device
Description of the device 1 - PIR sensor and light signaling 2 - Magnetic holder 3 - Battery cover 4 - Reset button 5 - Battery compartment... -
Page 5: Installation And Assembly
Installation and assembly Unscrew the back cover and remove the plastic insulation of the battery. - Page 6 Hold the reset button for 5 seconds until the sensor flashes and then pair it with your phone. Peel off the tape insulation on the back of the holder and stick it to the place of your choice. Then just attach the sensor to the magnetic holder and rotate it to your preference.
- Page 7 Notice for sensor installation For optimum performance, install the sensor at a height of approx. 2.2m.
- Page 8 For optimal PIR sensor function, we recommend placing it in an area without direct heat (e.g. radios, fireplaces, stoves), cooling (e.g. refrigerators, air conditioners) or sunlight. These sources of heat, cold and sunlight can affect the sensitivity of the sensor and lead to incorrect motion detection, which could cause unwanted alarms or non-detection of actual motion in the space.
- Page 9 Pairing with an app Installing the EMOS GoSmart app • The app is available for Android and iOS via Google play and the App Store. • Please scan the QR code to download the app.
- Page 10 Steps in the EMOS GoSmart mobile app Open the EMOS GoSmart app and confirm the privacy policy and click I agree. Select the registration option. Enter the name of a valid email address and choose a password. Confirm your consent to the privacy policy. Select register.
- Page 11 Select the Zigbee gateway to which you want to connect the device. Follow the instructions in the video and description. It is important to turn on and reset the sensor. The device is automatically found and then added.
-
Page 12: Controls And Functions
Controls and functions Icons and indicator lights Description of icons and controls in the application 1, 2 - Current status indicator 3 - Motion detection and automation trigger records 4 - Automation management (described in a separate chapter) 5 - Sensor settings •... - Page 13 Description of extension settings • Device information - Basic information about the device and its owner • Tap-to-Run and Automation - View scenes and automations assigned to the device. • Offline Notification - To avoid constant reminders, a notification will be sent if the device remains offline for more than 30 minutes.
- Page 14 Automation settings When you click on the automations option, you will see this interface with your scenes and automations. Scenes and automation are the main added value of this smart sensor compared to conventional PIR sensors. This device not only alerts on motion but can perform many other processes based on it.
-
Page 15: Troubleshooting Faq
Troubleshooting FAQ I can't get the devices to pair. What can I do? • Make sure you are using a 2.4GHz Wi-Fi network and have a strong enough signal • Allow the app all permissions in the settings • Make sure you are using the latest version of the mobile operating system and the latest version of the app I'm not getting notifications, why? •...
