Encryption Code Set - Zaxcom ZFR200 User Manual

Zaxcom ZFR 200 / 300

Encryption Code Set

ID1:000 ID0:000
If the encryption code is turned on the ZaxNet transmitted audio will be encrypted and can only
be listened to if the receiver has the matching encryption code entered. When receiving an audio
signal and the codes do not match, all that will be heard is white-noise or silence. So if using
encryption make sure the matching receiver has the same code.
These two sets of numbers are formed into a single six-digit encryption code which provides a
total of 16,777,216 possible combinations.
Please note that both of these codes should be set to 000 for normal un-encrypted operations
To adjust the encryption code
1. Momentarily press the MENU key to advance to the next character.
2. To change the designated character, press the INC or DEC key.
3. To exit this page, press and hold the MENU key for 1 second.
22
Extended Menu
