Zaxcom ZFR 200 / 300

ZaxNet Transmit Frequency Set

IFB TX FREQ:
2.420
This is where the ZaxNet transmit frequency is set.
The ZaxNet transmit frequency is the frequency that the ZaxNet transmitter will broadcast time code and
audio on for the purpose of confidence audio monitoring via an ERX receiver or Nomad. Please note this
transmitted audio is for quality control purposes and the expected range will be less than 20 feet.

IFB Receive Pulse Set

This menu will only appear if IFB is set to go into transmit mode.
IFB RX PULSE:
NEVER
IFB RX PULSE:
600 SECS
This is where you set how often the ZaxNet transceiver will stop sending and search for time code when it
is sending ZaxNet confidence audio.
When enabled this tells the ZaxNet transceiver to stop transmitting once every XXX seconds to go into
receive mode so it can re-jam its time code wirelessly via ZaxNet. You would use this when you are using
ZaxNet on the ZFR for confidence monitoring and you still want to update time code at set intervals. When
the ZFR searches for ZaxNet it will temporally go out of transmit mode for approximately 1 second as it
searches for ZaxNet time code.
• The settings are NEVER or any interval between 10 and 999 seconds.

IFB Transmit Power Level

IFB TX POWER: 7
This is where the power level of the ZaxNet transmitter is set.
• The power settings are any interval between 0 and 7 with 7 being the highest.
The ZaxNet transceiver will stay in transmit mode and never go into
receive mode.
In this example the ZaxNet transceiver will go out of transmit mode
every 10 minutes. You would use this setting if you are monitoring
audio via an ERX receiver and you still want the ZFR to update time
code.
15
Extended Menu
