Zaxcom ZFR 200 / 300

Extended Menu

High Pass Filter

HIGH PASS: OFF
The high pass filter is turned on and adjusted from this menu.
• The high pass filter range is 70Hz to 220Hz and can be adjusted in 10Hz increments.

Record Format Set

TX FORMAT:
MONO (US)
This menu is for adjusting the recording mode on the ZFR recorder.
• US MONO - This setting is used for mono recording.
• STEREO - This setting is used if you have a stereo ZFR and are recording a stereo source.
Please note that you must reboot the ZFR after changing this setting.

IFB Voting Enable

IFB VOTING
NORMAL (OFF)
This menu allows you to enable / disable the IFB Voting function.
The purpose of IFB voting is to allow the ZFR's ZaxNet receiver to choose and switch to the stronger
signal from two different ZaxNet transmitters. One purpose of this is if you are on a large set you can
place a second IFB transmitter at a different location and the ZaxNet receiver will choose the stronger
signal. To use the IFB voting feature just set the second IFB transmitters frequency to exactly 2MHz
higher than the first frequency.
Please note that the IFB voting is only available if the IFB in the unit will never go into transmit mode. So
the IFB RX to TX mode needs to be set to normal RX, and RX mode is not set to off.
13
