- Page 1 Installation and Operation Manual RoHS CEDES AG is certified according to ISO 9001: 2015 English Pages 1 – 16 Original version 117 941 | 240321 | V 1.0...
-
Page 2: Table Of Contents
- emitter is used. Troubleshooting Receiver edge Maintenance North America Disposal European Union Product label Light curtain Technical data Dimensions CEDES AG reserves the right to modify or change technical data without prior notice. © CEDES | V 1.0... -
Page 3: Safety Information
Do not use the sensor, controller or cables if any of these items has been damaged. Safety messages categories Keep the instruction manual on site. The cegard/Smart shall only be installed by authorized and Warning of serious health risks fully trained personnel! The installer or system integrator is WARNING fully responsible for the safe integration of the sensor. -
Page 4: Introduction Cegard/Smart System
Introduction cegard/Smart Overview cegard/Smart system The Figure 1 shows the principal of the cegard/Smart architecture. The light curtain emitter (Tx), the receiver The cegard/Smart system provides a complete elevator (Rx) and the CabSafe 3D sensor are all connected to the door protection solution that complies with: cegard/Smart controller. -
Page 5: Cegard/Smart Light Curtain
These beams are sequenced, one after the other Safety instructions at a specific frequency. The receiver is designed to only The cegard/Smart light curtain must be used in conjunction accept the specific pulse frequency from the emitter. This with a cegard/Smart or other compatible controller from enables the rejection of ambient light and thus enhances CEDES. -
Page 6: System Components
English System components General operation The infrared cegard/Smart light curtain consists of The cegard/Smart light curtain systems are supplied as a pair with an emitter and receiver edge and two connection • an emitter (Tx) and cables. The emitter projects an array of infrared light beams •... -
Page 7: Alignment
Reflective surface Do not install the cegard/Smart system in places where the emitter and receiver edges are directly exposed to light sources such as fluorescent tubes or energy saving lamps. - Page 8 14 ... 75 mm (0.5 ... 3") Gap between door sill and lower end of safety door edge approx. 5 mm (0.2") Figure 3: Typical cable guiding in a dynamic installation © CEDES | V 1.0...
- Page 9 6.3.1 Mounting options using spacer / mounting profile and vision shield The standard mounting kit in the North American cegard/Smart light curtain kit includes two (2) spacer profiles, one (1) mounting profile and two (2) vision shields. These component mount to the elevator door(s) and/or strike jamb in the following manner.
- Page 10 Drill the holes for mounting on the marked positions. Apply double-sided tape (EU) or felt strip (NA) to the middle of the light curtain. Make sure that the door surface is clean where the tape or felt strip is located. © CEDES | V 1.0...
-
Page 11: Electrical Installation
Therefore, do not guide cegard/Smart connection cables close to cables carrying high voltage and/or high current. The cegard/Smart cables should also be mounted as far away as possible from the door drive motor or motor inverter (VVVF-drives) to avoid EMI problems. -
Page 12: Installation According To Standards
To be compliant to the international standard EN 81-20 and/or North American standard ASME A17.1 / CSA B44, the cegard/Smart light curtain must be installed so that the lowest beam (bottom end) is positioned less than 25 mm above floor. -
Page 13: Troubleshooting
Avoid scratching the optical elements while cleaning. Disposal The components of the CabSafe 3D or cegard/Smart system should only be replaced if a similar protection device is installed. Disposal should be done using the most up-to-date recycling technology according to local regulations and laws. -
Page 14: Product Label
0 ... 3 m (0 ... 9.84 ft) Product label No. of optical elements Max. no. of beams Each cegard/Smart light curtain edge is labeled with a product label. The label is attached on the side of the Max. ambient light 100,000 Lux profile on each emitter and receiver. - Page 15 EMC emmision EN 12015:2021 EMC immunity EN 12016:2013 Vibration IEC 60068-2-6:2007 Shock IEC 60068-2-27:2008 Cable durability IEC 60227-2:2003 RoHS 2011/65/EU Certificates - Europe CE; EN 81-20:2020 - USA / Canada cCSAus; CSA B44.1:19 / ASME A17.5-2019 © CEDES | V 1.0...
-
Page 16: 11. Dimensions
Protection Lowest height beam Side view 2000 1,806 2,000 1,995 Tx: 1,828 Tx: n/a Rx: 1,828 Rx: 1,777 Detailed view: Ø 5 Ø 5 CEDES AG, Science Park | CH-7302 Landquart Phone: +41 81 307 2323 | info@cedes.com | www.cedes.com...
