Arzel® Zoning Technology
(AirBoss™ and 1200 Series Panels)
1) VOLTAGE TEST
a) 24 Volt AC
i) Check AC voltage at 24-VAC R & C terminals, no less than 21.6 Volts A/C
should be present from Arzel supplied Transformer
b) 24 Volt DC
i) Generate a call for "Y1", "Y2" & "G" at zone 1 only (use jumpers if needed),
and set all other zones to "Auto Fan" and "Off". (This will energize all but
one solenoid and put the board under its heaviest load)
ii) With board under full load, there should be no less than 24 Volts DC between
(SOLENOID " + ") and (BYPASS " D ") terminals
iii) If 24 Volts AC is present at 24VAC terminals and the DC Volts is less than
24, the board will need replaced
2) TESTING BOARD "OUTPUT" (EQUIPMENT FUNCTION) RELAYS.
a) Turn "Power" switch "ON" (Red LED On) and call for Heat from one or more
thermostats;
i) Is the Red "W1" LED lit at the "HVAC OUTPUT" terminal?
(1) Yes! LED is on
(a) Check for continuity (0 Ohms) between the "R" and "W1" terminals at
the "HVAC OUTPUT" terminal strip on Arzel board (wires removed).
(b) If no continuity (∞ ohms), the board must be replaced.
(c) If continuity is present (0 ohms), the board is OK and the problem is
with the HVAC equipment or a faulty wire between panel and
equipment.
(i) Turn panel Power switch "OFF" and Check voltage (A/C) between
(ii) No Voltage indicates problem with equipment control power or
(2) No! LED is not lit - Check for 24v ac between "W1" and "C" terminals at
the calling zone terminals.
Troubleshooting Guide
(40 VA for 2, 3, and 4 zone panels)
(100 VA for 6 and 8 zone panels)
HVAC Output "R" & "W" terminals (wires connected).
wiring.
("W1" with an "O" is an illegal call and will be ignored)
("W2" without a "W1" is an illegal call and will be ignored)
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1200 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Arzel 1200 Series

  • Page 1 (1) Yes! LED is on (a) Check for continuity (0 Ohms) between the “R” and “W1” terminals at the “HVAC OUTPUT” terminal strip on Arzel board (wires removed). (b) If no continuity (∞ ohms), the board must be replaced. (c) If continuity is present (0 ohms), the board is OK and the problem is with the HVAC equipment or a faulty wire between panel and equipment.
  • Page 2: Damper Operation

    To close a damper it must see a positive pressure of at least 25” wc. i) An open-ended “Airflow Indicator” (available through Arzel) connected from the bottom of the indicator to the solenoid port should show pressure by lifting the ball to the top of the indicator.
  • Page 3 5) AIR SIDE INTEGRITY CHECK a) Use the Arzel “ Air Flow Indicator “ to determine if and what zones are leaking air through tubing or damper actuators. Refer to instructions sent with the “Air Flow Indicator”.
  • Page 4 ICM Variable speed motor is ramping up and down. (1) Bypass is possibly oversized and/or not properly adjusted (a) Refer to Arzel Bypass Sizing chart, add volume damper to decrease capacity. (b) Adjust bypass to open only when air noise exceeds tolerable levels.
  • Page 5 Indicator (with the bottom port left open). 10) AIR SIDE INTEGRITY CHECK a) Use the Arzel “ Air Flow Indicator “ to determine if any damper actuators, tubing or fittings are leaking air. Refer to instructions sent with the “Air Flow Indicator”.
  • Page 6 ICM Variable speed motor is ramping up and down. (1) Bypass is possibly oversized and/or not properly adjusted (a) Refer to Arzel Bypass Sizing chart, add volume damper to decrease capacity. (b) Adjust bypass to open only when air noise exceeds tolerable levels.
