GECI Orange Diamond OD1200 User Manual

Portable plug-in charger system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PORTABLE PLUG-IN CHARGER SYSTEM
SAFETY INSTRUCTIONS AND WARNING:
Before to start using your battery charger, please take the time to read these instructions carefully. The owner's
manual is an important part of the charger. It's recommended to keep it in good condition for the lifetime of
the charger. It should be kept in a dry and clean place, always available to the users. To indicate important
instructions, the following blocks are used throughout this manual.
>>>CAUTION!<<<
This operation can be dangerous for the user.
>>>ATTENTION!<<<
This operation is important for the functionality and reliability of the charger.
GENERAL:
Battery charging products can cause serious injury or death, or damage to other equipment or property, if the
operator does not strictly observe all safety rules and take precautionary actions.
Safe practices must be learned through study and training before using this equipment.
Only qualified personnel should install, use, or service this equipment.
GECI
ORANGE DIAMOND CHARGER
™
USER'S MANUAL
GECIproducts.net
GREEN ENERGY CONCEPTS INC.
5833 Orr Road, Bldg 2
Charlotte, North Carolina, 28213
1.877.914.8999
©2022 GREEN ENERGY CONCEPTS, INC.
2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Orange Diamond OD1200 and is the answer not in the manual?

Questions and answers

Related Manuals for GECI Orange Diamond OD1200

Summary of Contents for GECI Orange Diamond OD1200

  • Page 1 2022 GECI ORANGE DIAMOND CHARGER ™ PORTABLE PLUG-IN CHARGER SYSTEM USER’S MANUAL SAFETY INSTRUCTIONS AND WARNING: Before to start using your battery charger, please take the time to read these instructions carefully. The owner’s manual is an important part of the charger. It’s recommended to keep it in good condition for the lifetime of the charger.

  • Page 2: Shock Prevention

    SHOCK PREVENTION: Bare conductors, or terminals in the output circuit, or ungrounded, electrically-live equipments can fatally shock a person. To protect against shock, have competent electrician verify that the equipment is adequately grounded and learn what terminals and parts are electrically HOT. The body’s electrical resistance is decreased when wet, permitting dangerous current to flow through the body.

  • Page 3: Medical And First Aid Treatment

    OD1200 - OD2400 [M2013SEP24V002GR] Service Manual In case of acid in the eyes, flush very well with clean water and obtain professional medical attention immediately. ________________________________________________________________________________________________________________ IPTION OF THE CHARGER GECI ORANGE DIAMOND CHARGER DESCRIPTION ™ been designed to charge Lead-Acid batteries.

  • Page 4: Installation

    GECI ORANGE DIAMOND CHARGER INSTALLATION ™ CONDITIONS OF USE: • Temperature (operation): from 5°C to 45°C • Temperature (storage): from –20°C to 60°C. • Relative Humidity: less than 75 %. >>>CAUTION!<<< Risk of electrical shock! The charger can be installed by qualified personnel only.
  • Page 5 Identify which of the 5 NOMINAL voltage values is closest to the REAL measured value. • Example 1: for a charger 1x110 , if the measured voltage is 118 VAC, the transformer should Example 1: for a charger 1x110 , if the measured voltage is 118 VAC, the be connected to the tap number 2, that corresponds to 120 VAC.

  • Page 6: How To Use The Charger

    [M2013SEP24V002GR] Service Manual ___________________________________________________________________________________________________________________________________________________ GECI ORANGE DIAMOND CHARGER PROGRAMMING ™ HOW TO USE THE CHARGER [V.300 – Oct 2014] OD1200 - OD2400 [M2013SEP24V002GR] Service Manual ___________________________________________________________________________________________________________________________________________________ HOW TO USE THE CHARGER PROGRAMMATION OF THE FINISHING CHARGE TIME The programmabie finishing charge times are 2 to 12 hours in the MRG Charge Controller.

  • Page 7: Charge Operation

    recommended to survey the operation of the charger when the battery remains co charger for more than 12 hours. BATTERY CONNECTION – AUTOMATIC VOLTAGE CHECK AND AUTOSTART: Connect the battery to the charger, using an adequate plug. When the battery is correctly connected, all the LEDs of the control panel w >>>ATTENTION!<<<...

  • Page 8: Automatic Data Saving

    take too long to reach the gassing voltage. The cause if this problem may be a wrong setting of the input voltage: if the in [M2013SEP24V002GR] Serv certain value (for example: 610 V) but the real voltage is lower (for exampl ____________________________________________________________________________________________________________________________ SAFETY TIMER –...
  • Page 9 While the equalization charge is in progress, the MRG Front Panel shows “EQUALIZING”: EQUALIZATION: The chargers Equalize the battery on a weekly basis. The operation is totally automatic. After the normal completion of the charge, the chargers wait for 15 hours, then it gives 4 equalization cycles of 30 minutes, with 15 hours of interval between each cycle.
  • Page 10 GECI, (2) the product is used under normal conditions for which designed, (3) the product is not instructions of GECI, (2) the product is used under normal conditions for which designed, (3) the product is not...
