ZINK ZN-31805-WHT Quick Start Manual

SPECIFICATION:
Power Source: 220-240V/AC
Power Frequency: 50/60Hz
Ambient Light: <3-2000LUX (adjustable)
Time Delay: Min.10sec±3sec
Max.30min±2min
Rated Load: Max.800W
400W LED
FUNCTION:
The Sensor can identify day and night: you can adjust its settings to operate in differing levels of ambient light.
when on the Max 'sun' setting, the lights will operate all day. When set to the minimum >3LUX it will only operate at night.
Once activated the light will operate for the set time, this will reset each time the sensor is triggered.
Good sensitivity
INSTALLATION ADVICE:
As the detector responds to changes in temperature, avoid the following situations:
Avoid pointing the detector towards objects with highly reflective surfaces, like mirrors etc.
Avoid mounting the detector near heat sources as heating vents, air conditionings, light etc.
Avoid pointing the detector towards objects that may move in the wind, such as curtains, tall plants etc.
CONNECTION:
Thea Conduit Mount
PIR sensor
INS ZN 31805 - B
Detection Range: 360°
Detection Distance: 8 m max(<24
Working Temperature: -20~+40
Working Humidity: <93%RH
Power Consumption: approx 0.5W
Installation Height: 2.2-4m
Detection Moving Speed: 0.6-1.5m/s
Warning. Danger of death through electric shock!
Must be installed by professional electrician.
Disconnect power source.
Cover or shied any adjacent live components.
Ensure device cannot be switched on.
Check power supply is disconnected.
This product should be disposed of responsibly
at the end of its life. Please recycle where
)
facilities exist. Check with your Local Authority
or retailer for recycling advice
(Waste Electrical and Electronic Equipment
Directive)
Poor sensitivity
