1.
General
A.
This procedure contains scheduled maintenance task data.
B.
This procedure has these tasks:
(1)
Landing Gear Tire Pressure Check
(2)
Landing Gear Tire Servicing
C.
The nitrogen that you use must have a minimum purity of 99.5 percent.
GOT 237, 238, 417-419
D.
Some airplanes have a tire pressure gage installed in the wheels. The tire pressure gage is part of
an assembly that includes the gage and the tire fill valve. You can use the gage for walk-around
inspections and other fast checks. You must use a separate calibrated gage with an approved dial
when you inflate a tire. You must also use a calibrated gage when the tire pressure indication must
be very accurate.
GOT ALL
TASK 12-15-51-780-801
2.
Landing Gear Tire Pressure Check and Tire Servicing
(Figure 301, Figure 302, Figure 303)
NOTE: This procedure is a scheduled maintenance task.
A.
General
(1)
This task has instructions for two methods to determine tire pressure.
(a)
Use standardized pressures for the main gear and nose gear tires (recommended).
(b)
Use the tire inflation limit charts to determine main gear and nose gear tire pressures
(optional).
B.
References
Reference
32-00-01-480-801
32-45-11 P/B 401
32-45-21 P/B 401
C.
Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference
SPL-1527
EFFECTIVITY
GOT ALL
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
LANDING GEAR TIRE - SERVICING
Title
Landing Gear Downlock Pins Installation (P/B 201)
MAIN LANDING GEAR WHEEL AND TIRE ASSEMBLY -
REMOVAL/INSTALLATION
NOSE LANDING GEAR WHEEL AND TIRE ASSEMBLY -
REMOVAL/INSTALLATION
Description
Inflator - Tire
737-700, -800
Part #: F70199-25 Supplier: 81205
Part #: F70199-52 Supplier: 81205
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
D633A101-GOT
12-15-51
Page 301
Oct 15/2019
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Boeing 737-600
Summary of Contents for Boeing 737-600
- Page 1 SPL-1527 Inflator - Tire 737-700, -800 Part #: F70199-25 Supplier: 81205 Part #: F70199-52 Supplier: 81205 12-15-51 EFFECTIVITY GOT ALL Page 301 D633A101-GOT Oct 15/2019 ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details...
- Page 2 For the nose landing gear tires, remove the cap cap [102]. SUBTASK 12-15-51-020-010 For the main landing gear tires, remove the cap [101]. 12-15-51 EFFECTIVITY GOT ALL Page 302 D633A101-GOT Feb 15/2019 ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details...
- Page 3 G00018 to the correct pressure. SUBTASK 12-15-51-610-013 Inflate main and nose gear tires to 205 ±5 psig (1413 ±34 kPa) for the 737-600/-700/-800/-900 airplanes but not 737-900ER. See Table 301. Table 301/12-15-51-993-812 Maintenance Actions for Main and Nose Gear Standardized Tire Pressures...
- Page 4 NOTE: The maximum taxi weight is the actual maximum taxi weight. Not the certified maximum taxi weight. 12-15-51 EFFECTIVITY GOT ALL Page 304 D633A101-GOT Feb 15/2019 ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details...
- Page 5 Send the wheel and tire assembly for an inspection to find the cause for the low tire pressure. 12-15-51 EFFECTIVITY GOT ALL Page 305 D633A101-GOT Feb 15/2019 ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details...
- Page 6 If you will not service the tires for the main landing gear tires, install the cap [101]. END OF TASK 12-15-51 EFFECTIVITY GOT ALL Page 306 D633A101-GOT Feb 15/2019 ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details...
- Page 7 12-15-51 EFFECTIVITY GOT 101-199, 201-215, 217, 219-236, 239-244, 247-250, 301-308, 310, 312-323, 327-399, 401-410, 415, 416, 430, 431, 434, 436-999 Page 307 D633A101-GOT Jun 15/2020 ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details...
- Page 8 1 POINT F73462 S0006561316_V2 Landing Gear Tire Servicing Figure 301/12-15-51-990-801 (Sheet 2 of 2) 12-15-51 EFFECTIVITY GOT 237, 238, 417-419 Page 308 D633A101-GOT Oct 15/2019 ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details...
- Page 9 Main Landing Gear Tire Inflation Limits Figure 302/12-15-51-990-802 (Sheet 1 of 2) 12-15-51 EFFECTIVITY GOT 101-199, 201-210, 213-215, 217, 219-244, 247-250, 304, 441 Page 309 D633A101-GOT Jun 15/2020 ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details...
- Page 10 Figure 302/12-15-51-990-802 (Sheet 2 of 2) 12-15-51 EFFECTIVITY GOT 211, 212, 301-303, 305-308, 310, 312-323, 327-399, 401-410, 415-419, 430, 431, 434, 436-440, 442-999 Page 310 D633A101-GOT Jun 15/2020 ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details...
- Page 11 LEGEND: 737-600 737-700/700IGW 737-800 737-900 737-900ER G37434 S0006561323_V3 Nose Landing Gear Tire Inflation Limits Figure 303/12-15-51-990-803 12-15-51 EFFECTIVITY GOT ALL Page 311 D633A101-GOT Oct 15/2015 ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details...
