- Page 1 User Guide ENG Witt freestanding wine appliances -2 WCIF60185-2BG WCF60172-1BG / WCF60172-2BG...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Warnings ......................3 Before loading and plugging in the wine cabinet ..........5 Grounding instructions ..................6 Installation ....................... 6 Installation drawings ..................8 Operation ....................... 11 Turning on your wine cabinet ................ 11 Operating noises .................... 11 Loading your wine cabinet ................ -
Page 3: Warnings
The information in this document is subject to modification without any prior notice. Some models are available in dedicated countries only. Witt offers no guarantee for our wine cellar if it is being used for any purpose other than that for which it was specifically designed. We cannot be held responsible for any error in this manual. - Page 4 R600a WARNINGS: For your safety observe the following recommendations. • This appliance contains a small quantity of R600a refrigerant which is environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the greenhouse effect. • During transportation and installation, ensure that the tubing of the refrigerant circuit is not damaged.
-
Page 5: Before Loading And Plugging In The Wine Cabinet
• WARNING: Do not damage the refrigerant circuit. WARNING: Do not use electrical appliances inside the food storage • compartments of the appliance, unless they are of the type recommended by the manufacturer. WARNING: If you do not use the machine for a long time, please unplug the •... -
Page 6: Grounding Instructions
Notes: • WCIF60185-2BG, WCF60172-1BG, WCF60172-2BG models are table-top and free-standing ss per the drawings thereafter. Wine cellar should be placed where the ambient temperature is proper (Please view the end of Manual). If the temperature is above or below this range, it will affect the performance of the cellar. -
Page 7: Installation
INSTALLATION INSTRUCTIONS 1. Please follow the installation diagram when installing wine cellars. No less than the minimum installation dimension, or it will affect the venting of cellar. 2. All wine cellars have a power switch located on the control panel, so power point location is not critical. -
Page 8: Installation Drawings
INSTALLATION DRAWINGS Ensure good ventilation according to the installation drawings, otherwise it will affect the wine cooler working normally. Note: The appliance must be positioned so that the plug is accessible after installed. WCIF60185-2BG... - Page 9 WCF60172-1BG/WCF60172-2BG...
- Page 10 INSTALLATION DRAWINGS (OPEN DOOR) WCIF60185-2BG WCF60172-1BG / WCF60172-2BG...
-
Page 11: Operation
TURNING ON YOUR WINE CELLAR Plug in and switch on the cellar by pressing on the power button for a few seconds. When you use the wine cellar for the first time (or restart the wine cellar after having it shut off for a long time), there will be a few degrees variance between the temperature you have selected and the one indicated on the LED readout. - Page 12 • Keep small gap between the walls and the bottles to allow air circulation. Like an underground cellar air circulation is important to prevent mould and for a better homogeneous temperature within the cellar. DANGER! • Do not overload your wine cellar to facilitate air circulation. Do not stack more than 1.5 rows of standard 0.75L bottles per shelves to •...
-
Page 13: Temperature Setting
TEMPERATURE SETTINGS Important: The LED displays by default the actual internal air temperature. The temperature of the power, before all Settings will be resumed after the electricity to power the pre-set temperature. The electrical board of all models comes with memory function. It is important to understand that there is a difference between the air temperature inside the wine cellar and the actual temperature of the wine: You will need to wait approximately 12 hours before noticing the effects of temperature adjustment due... -
Page 14: Control Panels
CONTROLS PANELS Control panel WCF60172-1BG ① ON/OFF the power button In the standby mode: press 3 seconds, the power is turned on, the whole machine starts. In the power-on state: press the power button, window 4 shows the countdown 3 2... - Page 15 Control panel WCF60172-2BG ① “ON/OFF” the power button Press the button 3 seconds to power off (Window ④ digital countdown displays 3, 2, 1,). Press again (without delay), the power turns on. ② Upper zone temperature setting up button ...
- Page 16 Control panel WCIF60185-2BG ① Power key Standby mode: short press the button, the power is switched on, the machine starts. Boot state: the duration of 3 seconds, the window 10 shows the countdown 321, power off, the whole machine off. ②...
- Page 17 ⑥ Child lock Boot state, the keyboard does not operate for more than 15 seconds, automatically locked, continued to press 3 seconds to unlock. ⑦ Child lock status prompt Indicates the locked state. Indicates the unlocked state. ⑧ Faulty system: ...
-
Page 18: Wine Serving Temperature Chart
WINE SERVING TEMPERATURE CHART All wines mature at the same temperature, which is a constant temperature set between 12ºC to 14ºC. The below chart is an indicative temperature chart to indicate the best temperature for drinking purposes. Wine Serving temperature Champagne NV, Sparkling, Spumante 6ºC Dry White Semillon, Sauvignon Blanc... -
Page 19: Defrosting/Condensation/Hygrometry/Ventilation
if the temperature of your wine cellar is constant (between 12ºC to 14ºC) your wines will be stored in perfect conditions. Not all wines will improve over the years. Some should be consumed at an early stage (2 to 3 years) while others have tremendous ageing capability (50 and over). All wines have a peak in maturity. -
Page 20: Sliding Shelves
SLIDING SHELVES Sliding wooden shelf installation and taking instruction: Shelf taking: According to below instruction drawing to pull out the shelf to support bracket ①, press two sides of sliding roller buckles and pull out the shelf following the arrow mark ②. Shelf installation: According to below instruction drawing to push in the shelf alignment with two sides of sliding roller following the arrow mark ③. - Page 21 1. To put the cabinet on open operation place, the door opened to the maximum angle. 2. Use small knife (2) to take off the decorative nail (1) on opposite side (Drawing 1). 3. Use the inner six angle screwdriver (Tool 5) to disassemble the screws (4) of drop-proof device (3), then remove the drop-proof device.
- Page 22 1.Decorative nail 2. Knife 3. Drop-proof device 4. M5 six angle 5. M5 six angle screwdriver 6. Door spindle core 7. Upper door hinge 8. Lower door hinge...
-
Page 23: Installation - Ventilation Frame
VENTILATION FRAME INSTALLATION METHOD 1. Take out Ventilation frame from cabinet, then take out 4 pcs 4 * 12 screws from accessory bag. 2. Open the door, align the ventilation frame to the four screw holes in the bottom of the cabinet and tighten the screw with Phillips screwdriver. OPERATION ANOMALIES Ensure that there is power to the electrical supply plug by connecting another electrical appliance to it. -
Page 24: Power Failure
POWER FAILURES In the event of a power interruption, all previous temperature settings are automatically preservation, and it will revert to a preset temperature setting. (See preset chart) Most power failures are corrected within a short period of time. An hour or two’s loss of power will not affect wine cellar’s temperatures. -
Page 25: Troubleshooting Guide
TROUBLESHOOTING GUIDE Common problems may easily be solved, saving you the cost of a possible service call. Please carefully read the instruction manual and revert to troubleshooting guide chart. PROBLEM POSSIBLE CAUSE Wine cellar Not plugged in. does not The appliance is turned off. operate. -
Page 26: Before Disposal Of The Appliance
BEFORE DISPOSAL OF THE APPLIANCE. 1. Disconnect the main plug from the main socket. 2. Cut off the main cable and discard it.
