ReelCraft TH80000 Series Operating Instructions Manual

Operating Instructions
Series TH80000 Spring Driven Hose Reels
TH86050 OMP118 TH86000 OMP118
TH88050 OMP118 TH88000 OMP118
Dimensions
B
C
D
SAFETY
Personal injury and/or equipment damage may result if proper
safety precautions are not observed.
• Ensure that reel is properly installed before connecting input and
output hoses.
• Bleed fluid/gas pressure from system before servicing reel.
• Before connecting reel to supply line, ensure that pressure does
not exceed maximum working pressure rating of reel.
• Remember, even low pressure is very dangerous and can cause
personal injury or death.
• Be aware of machinery and personnel in work area.
Reelcraft International Inc. • Ph: +44 (0) 1536 406999 • Fax: +44 (0) 1536 406777
Unit 17 - Cronin Courtyard, Weldon South Industrial Estate, Corby - Northamptonshire NN18 8AG
europe@reelcraft.com • www.reelcraft.com/europe
A 645 mm
B 610 mm
A
C 254 mm
D 152 mm
E 327 mm
F
E
F 206 mm
Figure A
IMPORTANT
Read this manual carefully before installing, operating or
servicing this equipment.
• If a leak occurs in the hose or reel, remove system pressure
immediately.
• A high tension spring assembly is contained within the reel.
Exercise extreme caution.
• Pull hose from reel by grasping the hose itself, not the control
valve.
• If reel ceases to unwind or rewind, remove system pressure
immediately. Do not pull or jerk on hose!
• Treat and respect the hose reel as any other piece of machinery,
observing all common safety practices.
Form# R964-998 Rev: 2/2016
