- Page 1 Short Throw Motorized Installation Instructions INSTALLERS: PLEASE LEAVE THIS MANUAL WITH THE OWNER. Doc. # 400280 | v. 1.0 | April 2024...
- Page 2 Innovations’ option) the defective part of the merchandise. Returns for service should be made to your Screen Innovations' dealer. If it is necessary for the dealer to return the screen or part to Screen Innovations, transportation expenses to and from Screen Innovations are payable by the purchaser and Screen Innovations is not responsible for damage in shipment.
-
Page 3: Table Of Contents
Parts In The Box – Short Throw Motorized . . . . . . . . . . . . . . . . -
Page 4: Parts In The Box - Short Throw Motorized
PARTS IN THE BOX – SHORT THROW MOTORIZED Screen Remote Control Locking plug(2) M5*10 Flat Head Screw(4) 5x40 tapping screws(8) Ceiling hanging Motor limit Floating Expansion fixture(8) bracket(2) setting tool(1) brackets(2) • Please prepare for suitable tools such as gradienter, tape, marker, etc •... -
Page 5: Wall / Ceiling Installation
WALL / CEILING INSTALLATION Install bracket onto wall/ceiling that can bear such weight, and keep screen two sides on a same level. (Distance from casing end with 10cm), as below figure: Loosen the down screw until the screw can cover the casing, as figure: Screw to lock Lock piece... -
Page 6: Ceiling Hanging Method
WALL / CEILING INSTALLATION Hold the casing two ends flatly onto the bracket then push into the bracket, when the locking tooth fixed, you will hear a locking sound that means screen already fixed onto bracket safely. Lock screw and fix screen. As figure: The button Rut, for fix for uninstall... -
Page 7: Things To Know Before Installing
CEILING HANGING METHOD Take reference same as wall/ceiling installation, measure installation distance and mark position, the fix screen casing steady with bracket. According to site installation height, install hook onto ceiling, then hang the screen through bracket hole. As figure: Note: Before operate screen, make sure the sticker on casing and under bar is removed. -
Page 8: Power Connect
POWER CONNECT Short Throw Motorized screen will pre-equip with standard plug for your local market, only just connect plug to the socket, you can enjoy the use of the screen immediately. FABRIC CONTROL INSTRUCTION Intelligent motorized screen has 4 control options:... - Page 9 FABRIC CONTROL INSTRUCTION B -MI for IR: AC127/ -MF for RF: AC123 • UP : screen UP • STOP: screen STOP • DOWN: screen DOWN • Mirco-up: retract the screen in small increment • Mirco-down: lower the screen in small increment •...
- Page 10 FABRIC CONTROL INSTRUCTION C. Dry contact control: Please check the wire and function in the below sheet and picture for RJ12 and RJ45: Wire Size Common Small Stop Down Cassette Wire D. RS485 or RS232 control: RS485 / RS232 port setting: •...
- Page 11 FABRIC CONTROL INSTRUCTION Hexadecimal control code: • Up: ff ee ee ee dd • Stop: ff ee ee ee cc • Down: ff ee ee ee ee • Some central control need to reset address code: ff ee ee ee aa Note: •...
- Page 12 FABRIC CONTROL INSTRUCTION Motorized screen (M) circuit diagram: Screen retract height (Up limit) and extend height (down limit) adjustment: Screen retract Common ground AC220~230V Screen extend 50~60Hz,40W Yellow Green If have to adjust height limit for installation environment reasons, you can adjust the limit setting by using a provided adjustment bar insert into the adjustment hole which on the left down area of motor As below figure: Note: When screen retract height over the setting limit, fabric will automatically lower down.
-
Page 13: Maintain Screen
MAINTAIN SCREEN For long lasting enjoying the best viewing experience of ST Motorized screen, please retract screen into casing while not use. Before retracting into casing, please check screen front and back side to ensure surface has no obvious dust, insects or anything dirty. If there’s anything dirty, please use soft cloth clean it carefully first. - Page 14 Screen Innovations 9715-B Burnet Rd, Suite 400 Austin, TX 78758 512.832.6939 www.screeninnovations.com Doc. # 400280 | v. 1.0 | April 2024...
