- Page 1 Dell Neworking S4810–Open Networking (ON) Installation Guide April 2014...
- Page 2 Notes, Cautions, and Warnings NOTE: A NOTE indicates important information that helps you make better use of your computer. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
-
Page 3: Table Of Contents
Contents 1 About this Guide......................5 ..........................5 Information Symbols ..........................6 Related Documents 2 The S4810–ON System....................7 ............................7 Introduction ....................8 Orderable S4810–ON Components ............................8 Prerequisite ..............................9 Features ............................... 9 Ports ............................9 System Status .............................9 LED Displays 3 Site Preparations......................11 ............................11 Site Selection ..........................11... - Page 4 ......................24 Installing an AC Power Supply ......................25 Replacing an AC Power Supply 6 Fans..........................27 ............................27 Components ........................28 Installing a Fan Module ........................28 Replacing a Fan Module 7 Console Ports......................31 ..................31 Accessing the RJ-45 Console Port (RS-232) ...............32 Access the RJ-45 Console Port with a DB-9 Adapter 8 Specifications......................
-
Page 5: About This Guide
About this Guide This guide provides site preparation recommendations, step-by-step procedures for rack mounting and desk mounting, inserting optional modules, and connecting to a power source. CAUTION: To avoid electrostatic discharge (ESD) damage, wear grounding wrist straps when handling this equipment. WARNING: Only trained and qualified personnel can install this equipment. -
Page 6: Related Documents
Related Documents For more information about the S4810–ON system, refer to the Dell Networking S4810–Open Networking (ON) Getting Started Guide. NOTE: For the most recent documentation, visit iSupport: http://www.dell.com/support/my- support. About this Guide... -
Page 7: The S4810-On System
The following sections describe the Dell Networking S4810–ON system. Introduction The Dell Networking S4810–ON platform is a next-generation switch/router designed to meet the requirements for distributed data center cores. It is a one-rack unit (RU) chassis that supports 48 ports of 10GbE small form-factor pluggable plus (SFP+) and four quad small form-factor pluggable plus (QSFP+) ports. -
Page 8: Orderable S4810-On Components
S4810–ON Series — AC Power supply with airflow from the PSU side to the I/O side For a list of supported optics, refer to the S4810–ON data sheet at http://www.dell.com or contact your Dell Networking representative. Prerequisite To successfully install the S4810–ON, ensure that you have the following components. •... -
Page 9: Features
• Ground cable (not included, optional) • Ground cable screws (included) • Copper/fiber cables Other optional components are: • Additional power supply unit • Additional fan module • Additional mounting brackets (if installing in a four-post rack or cabinet) Features The S4810–ON offers the following features. - Page 10 • System Figure 3. S4810–ON LEDs MASTER The S4810–ON System...
-
Page 11: Site Preparations
Site Selection Install Dell Networking equipment in restricted access areas. A restricted access area is one in which service personnel can only gain access using a special tool, lock, key or other means of security and access is controlled by the authority responsible for the location. -
Page 12: Rack Mounting
Use the S4810–ON in a common bond network (CBN). Connect the grounding cables as described in Install the S4810-ON. Fans and Airflow The S4810–ON fans support two airflow options. Be sure to order the fans suitable to support your site’s ventilation. Use a single type of airflow fan in your system. -
Page 13: Storing Components
Storing Components If you do not install your S4810–ON and components immediately, Dell Networking recommends properly storing the system and all optional components until you are ready to install them. WARNING: ESD damage can occur when components are mishandled. Always wear an ESD- preventive wrist or heel ground strap when handling the S4810–ON and its accessories. -
Page 15: Install The S4810-On
The brackets are sent in a package with the system. NOTE: Dell Networking recommends attaching the brackets at the power supply unit (PSU) side. This set up provides the greatest weight support for the chassis in the rack or cabinet. -
Page 16: Installing The System Into A Two-Post Rack Or Cabinet
To attach the brackets to the system, follow these steps. Take the brackets and screws out of their packaging. Attach the brackets to the PSU sides of the system using four screws for each bracket. Attach the bracket so that the “ear” is parallel to the PSU and the outside of the system. Figure 4. -
Page 17: Attaching The Mounting Brackets Into A Four-Post Rack Or Cabinet
NOTE: Dell Networking recommends using one person to hold the S4810–ON chassis in place while another person attaches the brackets to the posts. Attach the bracket “ears” to the rack or cabinet posts using the two screws for each bracket. Ensure the screws are tightened firmly. -
Page 18: Installing The System Into A Four-Post Rack Or Cabinet
Attach the brackets to the PSU sides of the chassis using four screws for each bracket. Attach the bracket so that the “ear” is parallel to the PSU and the outside of the chassis. Figure 6. Attaching the Mounting Brackets into a Four-Post Rack or Cabinet View from the chassis I/O side Connect to the rack or cabinet Screws... -
Page 19: Attaching The Ground Cable
To attach the ground cable to the chassis, use a single M4x0.7 screw. The cable itself is not included with the S4810–ON. To properly ground the chassis, Dell Networking recommends using a 6AWG one-hole lug, #10 hole size, 63" spacing (not included in shipping). The one- hole lug must be a UL recognized, crimp-type lug. -
Page 20: Installing The Sfp+ And Qsfp+ Optics
Attach the one-hole lug to the chassis using the supplied 10-32 screw with the captive internal tooth lock washer. Torque the screw to 20 in-lbs. Figure 8. Attaching the Ground Cable Lug hole Ground Screw Attach the other end of the ground cable to a suitable ground point. The rack installation ears are not a suitable grounding point. -
Page 21: Remove The Sfp+ And Qsfp+ Optics
Supply Power and Power Up the System Supply power to the S4810–ON after it is mounted in a rack or cabinet. Dell Networking recommends re-inspecting your system prior to powering up. Verify that: • the equipment is properly secured to the rack and properly grounded. -
Page 22: After Installing The S4810-On
Figure 9. AC Power Connection Power Connection After Installing the S4810–ON After you have securely installed and powered on the S4810-ON, refer to your ONIE-compatible third- party operating system documentation to configure your system. Install the S4810–ON... -
Page 23: Power Supplies
PSUs are required for full redundancy, but the system can operate with a single PSU. NOTE: If you use a single PSU, install a blank plate in the other PSU slot. Dell Networking recommends using power supply 2 (PSU2) as the blank plate slot. -
Page 24: Installing An Ac Power Supply
PSU2 Grab Handle NOTE: If you use a single PSU, you must install a blank plate in the other PSU slot. Dell Networking recommends using power supply 2 (PSU2) as the blank plate slot. Take the PSU out of the shipping box. -
Page 25: Replacing An Ac Power Supply
Technical Support. NOTE: If you use a single PSU, you must install a blank plate in the other PSU slot. Dell Networking recommends using power supply 2 (PSU2) as the blank plate slot. Disconnect the power cable from the PSU. -
Page 27: Fans
Fans The S4810–ON comes from the factory with one power supply unit (PSU) and two fan modules installed in the system. If two or more fans are installed and running, the fan modules are hot-swappable. NOTE: To run the system, both slots must have operating fan units. If a module is not installed in each slot (either as part of the PSU or as an independent fan module), the system shuts down in one minute. -
Page 28: Installing A Fan Module
Figure 11. S4810–ON Fan Module PSU1 Fan Module 1 Fan Module 2 Grab Handle PSU2 Installing a Fan Module The fan modules in the S4810–ON are field replaceable. Module slot 0 is on the left side of the chassis; module slot 1 is on the right side of the chassis. CAUTION: DO NOT mix airflow directions. - Page 29 Tighten the captive screws on the replacement module with a screwdriver. Ensure that the module is secure. Fans...
-
Page 31: Console Ports
Console Ports You can access the S4810–ON directly through the console port at the input/output (I/O) side of the system. Accessing the RJ-45 Console Port (RS-232) The RS-232/RJ-45 console port is labeled on the upper-right-hand side of the S8410–ON chassis (the I/O side) (as shown in the following illustration). -
Page 32: Access The Rj-45 Console Port With A Db-9 Adapter
Access the RJ-45 Console Port with a DB-9 Adapter If the DTE has a DB-9 interface, you can connect to the console using an RJ-45 to DB-9 adapter along with the RJ-45 rollover cable. The following table lists the pin assignments. Table 1. -
Page 33: Specifications
Specifications This chapter lists the S4810–ON specifications. Chassis Physical Design Table 2. Chassis Physical Design Parameter Specifications Height 1.73 inches (4.4 cm) Width 17.32 inches (44.0 cm) Depth 18.11 inches (46 cm) Chassis weight with factory-installed components 14.39 pounds (approx.) (6.54 kg) Front: 5-inches (12.7 cm) Rack clearance required Rear: 5-inches (12.7 cm) -
Page 34: Ieee Standards
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Dell Networking is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications in the equipment. -
Page 35: Japan: Vcci Compliance For Class A Equipment
Email: EMEA Central Sales Japan: VCCI Compliance for Class A Equipment WARNING: Use the AC power cords with Dell Networking equipment only. Do not use Dell Networking AC power cords with any unauthorized hardware. This is Class A product based on the standard of the Voluntary Control Council For Interference by Information Technology Equipment (VCCI). -
Page 36: Safety Standards And Compliance Agency Certifications
Networking encourages owners of information technology (IT) equipment to responsibly recycle their equipment when it is no longer needed. Dell Networking offers a variety of product return programs and services in several countries to assist equipment owners in recycling their IT products. -
Page 37: Removing The Sd Card
EEE on the environment and human health due to the potential presence of hazardous substances in EEE. Dell Networking products, which fall within the scope of the WEEE, are labeled with the crossed-out wheelie-bin symbol, as shown above, as required by WEEE. -
Page 38: Replacing The Battery On The S4810-On
The lithium battery is not field replaceable. Only authorized personal should remove and replace the battery. If the battery requires replacement, contact Dell Networking Technical Support. WARNING: ESD damage can occur if components are mishandled. Always wear an ESD- preventive wrist or heel ground strap when handling the S4810–ON and its components. As with all electrical devices of this type, take all the necessary safety precautions to prevent injury when installing this system. - Page 39 To open the case, follow these steps. Remove the small Phillips screws that connect the top of the case to the body. There are three screws evenly spaced across the rear and three screws evenly spaced along each side of the case. Slide the top backwards until its front flange slides free of the faceplate then lift it off.
- Page 40 Customer participation is important to minimize any potential effects of batteries and accumulators on the environment and human health due to the potential presence of hazardous substances. For proper collection and treatment, contact your local Dell Networking representative. Specifications...
- Page 41 Figure 18. The European WEEE Symbol For California: • Perchlorate Material — Special handling may apply. • Refer to http://www.dtsc.ca.gov/hazardouswaste/perchlorate The foregoing notice is provided in accordance with California Code of Regulations Title 22, Division 4.5 Chapter 33. Best Management Practices for Perchlorate Materials. Specifications...
-
Page 43: Technical Support
Requesting a Hardware Replacement The iSupport Website iSupport provides a range of documents and tools to assist you with effectively using Dell Networking equipment and mitigating the impact of network outages. Through iSupport you can obtain technical information regarding Dell Networking products, access to software upgrades and patches, and open and manage your Technical Assistance Center (TAC) cases. -
Page 44: Requesting A Hardware Replacement
– Using the Create Service Request form on the iSupport page (refer to Contacting the Technical Assistance Center). – Contacting Dell Networking directly by email or by phone (refer to Contacting the Technical Assistance Center). Provide the following information when using email or phone: Part number, description, and serial number of the component.
