- Page 1 Dell Networking S4048–Open Networking (ON) Getting Started Guide Regulatory Model: S4048–ON...
-
Page 2: Notes, Cautions, And Warnings
Notes, Cautions, and Warnings NOTE: A NOTE indicates important information that helps you make better use of your computer. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death. -
Page 3: About This Guide
For complete installation, configuration, and update information, refer to the following documents at www.dell.com/support: Table 1. S4048-ON Documents Information Documentation Hardware installation and power-up instructions Dell Networking S4048-Open Networking (ON) Installation Guide Configuration Dell Networking Configuration Guide for the S4048- Open Networking (ON) System... -
Page 4: Install The Hardware
Install the Chassis To install the S4048–Open Networking (ON) system, Dell Networking recommends completing the installation procedures in the order presented here. NOTE: Always handle the system and its components with care. Avoid dropping the S4048–ON chassis or its field replaceable units. -
Page 5: Rack Mounting Safety Considerations
Rack Mounting Safety Considerations • Rack mounting — You may either place the switch on a rack shelf or mount the switch directly into a 19" wide, EIA-310-E- compliant rack. • Rack loading — Overloading or uneven loading of racks may result in shelf or rack failure, which may damage the equipment and cause personal injury. -
Page 6: Installing The Dell Readyrails System
Installing the Dell ReadyRails System The ReadyRails rack mounting system is provided to easily configure your rack so that you can install your switch. Install the ReadyRails system using the 1U tool-less method or one of three possible 1U tooled methods (two-post flush mount, two-post center mount, or four-post threaded). - Page 7 (on the switch side of the rail) and remove each casting. Retain the castings for future rack requirements. It is not necessary to remove the rear flange castings. Attach one rail to the front post flange with two user-supplied screws. Refer to item 2 in the following figure.
- Page 8 Figure 3. Two-Post Center-Mount Configuration Four-Post Threaded Configuration To install the Dell ReadyRails system using the four-post threaded configuration, follow these steps. For this configuration, remove the flange ear castings from each end of the ReadyRails assemblies. Use a Torx driver to remove the two screws from each flange ear and remove each casting. Refer to item 1 of the following figure.
- Page 9 Figure 4. Four-Post Threaded Configuration Install the S4048-ON System You can mount the system in the 1U front-rack or 1U two-post (flush and center) configurations. The following is an example of a front-rack configuration. For the 1U two-post (flush and center) configurations, slide the system into the rails in the same manner as the four-post configurations.
- Page 10 Figure 5. Attaching the Switch Rails After you have installed both switch rails, line them up on the previously mounted Ready-Rails and slide the switch in until it is flush with front of rack. About 3 inches before you fully insert your system, the rail locking feature engages to keep the switch from inadvertently sliding out of the rack and falling.
-
Page 11: Attaching The Ground Cable (Optional)
The S4048–ON requires one M4x0.7 screw for attaching a ground cable to the chassis. To properly ground the chassis, Dell Networking recommends a 6 AWG one-hole lug, #10 hole size, 63" spacing. The one-hole lug must be a UL-recognized, crimp-type lug. -
Page 12: Important Points To Remember
PSUs for full redundancy and additional cooling. To avoid overheating when the switch is running with only a single PSU, Dell Networking recommends using PSU1 (on the left) and covering the second PSU slot opening (PSU2) with a blank plate. -
Page 13: Installing A Fan Module
Figure 8. Install the AC Power Supply Unit Switch slot Attach the power cables from the switch PSU to the external power source. NOTE: The system is powered-up as soon as you connect the power cord between the system and the power source. Repeat steps 1 through 3 for the second PSU. -
Page 14: Installing The Sfp+ And Qsfp+ Optics
Supply Power and Power Up the System Supply power to the S4048–ON after the chassis is mounted in a rack or cabinet. Dell Networking recommends re-inspecting your system prior to powering up. Verify that: • The equipment is properly secured to the rack. -
Page 15: After Installing The S4048-On
(for example, new equipment installation). After Installing the S4048–ON After you have securely installed and powered on the S4048-ON, to configure your system, refer to your ONIE-compatible operating system documentation. Install the Hardware... -
Page 16: Dell Networking Os
To initially configure the Dell Networking operating system (OS), use the following sections. NOTE: This chapter applies ONLY if you already have the Dell Networking OS installed on your system from the factory. If you are installing a third-party OS, refer to your third-party OS documentation. -
Page 17: Navigating Cli Modes
Navigating CLI Modes The Dell Networking OS prompt changes to indicate the CLI mode. You must move linearly through the command modes, except for the end command which takes you directly to EXEC Privilege mode and the exit command which moves you up one command mode level. -
Page 18: Default Configuration
Signal Default Configuration When you install the Dell Networking OS onto your S4048–ON system, it is not configured when you power up for the first time (except for the default host name, which is Dell). You must configure the system using the CLI. -
Page 19: Configuring A Host Name
Management routes are separate from IP routes and are used to manage the S4048–ON through the management port. • Configure a management route to the network from which you are accessing the system. CONFIGURATION mode management route ip-address/mask gateway Dell Networking OS... -
Page 20: Configuring The Enable Password
(DES)-encryption method. • enable secret — stores the password in the running/startup configuration using a stronger, MD5- encryption method. Dell Networking recommends using the enable secret password. • Create a password to access EXEC Privilege mode. CONFIGURATION mode enable [password | secret] [level level] [encryption-type] password Creating a Port-based VLAN The default VLAN (VLAN 1) is part of the system startup configuration and does not require configuration. - Page 21 VLAN ID to the Default VLAN, use the default vlan-id vlan-id command from the configuration mode. • Access INTERFACE VLAN mode of the VLAN to which you want to assign the IP address then configure an IP addresses and mask on the interface. INTERFACE mode ip address ip-address mask [secondary] Dell Networking OS...
-
Page 22: Connect The S4048-On To The Network
Connect the S4048–ON to the Network After you have completed the hardware installation and software configuration for the S4048–ON system, connect to your company network by following your company’s cabling requirements. Dell Networking OS... -
Page 23: Technical Specifications
Technical Specifications This chapter lists the S4048–ON specifications. NOTE: Operate the system at an ambient temperature not higher than 113°F (45°C). CAUTION: Lithium Battery Caution: To avoid the possibility of an explosion, always replace the battery correctly. NOTE: Replace the battery only with the same or an equivalent type. Dispose of the batteries according to the manufacturer's instructions.
