- Page 1 OWNER’S MANUAL PORTABLE P18 y P18WF HTW-PC-035P18 | HTW-PB-035P18 HTW-PBS-035P18 | HTW-PB-035P18WF HTW-PC-035P18WF Thanks for choossing our product. Please, read carefully this manual before using the product...
-
Page 2: Table Of Contents
Page: 2/15 Content Notes………………………………………………….…..3 II. Features and Components............5 III. Installation and Adjustment............ 7 IV. Control Setting................9 V. Drainage Instructions ............. 13 VI. Maintenance………………………………………………… VII. Troubleshooting ..............….. 15 VIII. Appendix …………………………………………………… 16... -
Page 3: Notes
Page: 3/15 Thank you for choosing the luxurious and elegant mobile air conditioning. Please keep the manual for later review, and read the manual carefully before use. I. Notes Notes: *The air conditioning is only suitable for indoor use, and is not suitable for other applications. - Page 4 Page: 4/15 position. *The machine should stay away from gasoline, flammable gas, stoves and other heat sources. * Don't disassemble, overhaul and modify the machine arbitrarily, otherwise it will cause a machine malfunction or even bring harm to persons and properties. To avoid danger, if a machine failure occurs, ask the manufacturer or professionals to repair it.
-
Page 5: Features And Components
Page: 5/15 II. Features and Components 1. Features New look, compact structure, streamlined machine, aristocratic atmosphere. With cooling, heating (single cold with no such function), dehumidification and fan function, Continous Water Drainage Functions Automatic swing leaf in the outlet has automatic air swing function, and the outlet can be covered when the machine is turned off to prevent dust from entering the body. - Page 6 Page: 6/15 2. Components:...
-
Page 7: Installation And Adjustment
Page: 7/15 III. Installation and Adjustment 1. Installation: Warning: before using the mobile air conditioning, keep it upright for at least two hours. The air conditioning can be easily moved in the room. In the moving process, ensure that the air conditioning is in the upright position and the air conditioning should be placed on a flat surface. - Page 8 Page: 8/15 2）Elongate the heat pipe and snap the flat end of the heat pipe joints into the elliptical hole of the window sealing plate assembly (as shown in Figure 5 and Figure 6) . Notes: 1. the flat end of the heat pipe joints must be snapped into place. 2.
-
Page 9: Control Setting
Page: 9/15 IV. Control Setting Operating instructions: LED Control Panel Operation interface is as follows: when the machine is powered on for the first time, the buzzer will play power-on music, and then the machine will get into standby status. 2: Power Key: press the key to turn on and turn off the machine. - Page 10 Page: 10/15 6: Timing Key: In the case of power on, press the key to close timing; in the case of power off, press the key to open timing. Press the key, when the timing symbol flashes, press up and down key to select the required timing value.
- Page 11 Page: 11/15 4. Down: press the key to reduce temperature and timing set value. 5. Fan: press the key to select high, medium and low wind speed output circularly. 6. Timer: press the key to set timing value. 7.Swing: Press he key to open or close swing style.
-
Page 12: Drainage Instructions
Page: 12/15 V. Drainage Instructions 1. Manual drainage: 1）When the machine stops after the water is full, turn off the machine power and unplug the power plug. Notes: Please move the machine carefully, so as not to spill the water in the water pan at the bottom of the body. -
Page 13: Maintenance
Page: 13/15 VI. Maintenance Cleaning: before cleaning and maintenance, turn off the machine and unplug the plug. 1. Clean the surface Clean with surface of machine with a wet soft cloth. Don't use chemicals, such as benzene, alcohol, gasoline, etc.; otherwise, the surface of the air conditioning will be damaged or even the whole machine will be damaged. -
Page 14: Troubleshooting
Page: 14/15 drainage pipe becomes dry, so as to keep the inside of the body in a dry state and prevent it from mildewing. 3: Turn off the machine, unplug the power plug, and wrap the power cord around the wrapping post;... -
Page 15: Appendix
Page: 15/15 VIII.Appendix Fuse Parameters Type: 5TE or SMT Voltage: 250V Current: 3.15A Schematic Diagram Capillary Condenser Compressor Evaporator All the technical and specific parameters,please refer to product nameplate. Due to continuous improvement,we reserve the right to change some design without any notice. - Page 16 C./ Industria, 13 l Polígono Industrial El Pedregar 08160 Montmeló Barcelona (Spain) Phone: (0034) 93 390 42 20 Fax: (0034) 93 390 42 05 info@htwspain.com www.htwspain.com...
