  • Page 1 P4AL-800 P4AL-800M User Manual Version 1.0 Published August 2003 Copyright©2003 ASRock INC. All rights reserved.
  • Page 2 (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the manual or product.

  • Page 3: Table Of Contents

    3.1.1 BIOS Menu Bar ............17 3.1.2 Legend Bar ............. 17 3.2 Main Menu ..............18 3.3 Advanced, Security, Power, Boot, and Exit Menus ..20 4 Software Support ........... 21 4.1 Installing Operating System ........... 21 4.2 Support CD Information ..........21 4.2.1 Running Support CD ..........

  • Page 4: Introduction

    It delivers excellent performance with robust design conforming to ASRock’s commitment to quality and endurance. Chapter 1 and 2 of this manual contain introduction of the motherboard and step-by- step installation guide for new DIY system builders. Chapter 3 and 4 contain basic BIOS setup and Support CD information.

  • Page 5: Specifications

    1 AGP slot, supports 1.5V, 8X / 4X AGP card (see CAUTION 3) USB 2.0: 4 default USB 2.0 ports and one extra set of USB 2.0 header to support two additional USB 2.0 ports upgrade (see CAUTION 4) ASRock I/O : PS/2: 1 keyboard port / 1 mouse port;...
  • Page 6 To improve heat dissipation, remember to spray thermal grease between the CPU and the heatsink when you install the PC system. Do NOT plug a 3.3V AGP card in the AGP slot on P4AL-800 / P4AL-800M motherboard! It may cause permanent damage! ®...

  • Page 7: Motherboard Layout (P4Al-800)

    CPU socket External speaker connector (SPEAKER1) CPU fan connector (CPU_FAN1) South Bridge controller North Bridge controller Clear CMOS (CLRTC1, 3-pin jumper) 184-pin DDR DIMM slots PCI slots (PCI 1- 5) CPU heatsink retention module AUDIO CODEC Primary IDE connector (IDE1, Blue)

  • Page 8: Motherboard Layout (P4Al-800M)

    CPU socket External speaker connector (SPEAKER1) CPU fan connector (CPU_FAN1) South Bridge controller North Bridge controller Clear CMOS (CLRTC1, 3-pin jumper) 184-pin DDR DIMM slots PCI slots (PCI 1- 5) CPU heatsink retention module AUDIO CODEC Primary IDE connector (IDE1, Blue)

  • Page 9: Asrock I/O

    1.5 ASRock I/O (P4AL-800 / P4AL-800M) Parallel port Line Out (Lime) RJ-45 port USB 2.0 ports Game port Serial port (COM1) Microphone (Pink) PS/2 keyboard port (Purple) Line In (Light Blue) PS/2 mouse port (Green)

  • Page 10: Installation

    P4AL-800 is an ATX form factor (12.0" x 7.8", 30.5 x 19.8 cm) motherboard; P4AL-800M is a Micro ATX form factor (9.6" x 7.8", 24.4 x 19.8 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it.

  • Page 11: Cpu Installation

    CPU into the socket to avoid bending of the pins. Step 4. When the CPU is in place, press it firmly on the socket while you push down the socket lever to secure the CPU. The lever clicks on the side tab to indicate that it is locked.

  • Page 12: Installation Of Memory Modules (Dimm)

    DIMMs or the system components. Step 1. Unlock a DIMM slot by pressing the retaining clips outward. Step 2. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. notch break...

  • Page 13: Expansion Slots

    2.6 Expansion Slots (PCI and AGP Slots) PCI slots: PCI slots are used to install expansion cards that have the 32-bit PCI interface. AGP slot: The AGP slot is used to install a graphics card. The ASRock AGP slot has a special locking mechanism which can securely fasten the graphics card inserted.

  • Page 14: Jumpers Setup

    2 Note: When you connect speakers in back panel and front panel at the same time, 1. If the jumpers JL1 and JR1 are short (see fig. 1), both front panel and rear panel audio connectors can work. 2. If both jumper caps on JL1 and JR1 are removed (see fig. 2), only front panel audio works.

  • Page 15: Connectors

    FLOPPY1 Pin1 Red marking (see p.7/p.8 item 10) Note: Match the red marking on the floppy ribbon cable with Pin1. Primary IDE connector (Blue) Secondary IDE connector (Black) (39-pin IDE1, see p.7/p.8 item 7) (39-pin IDE2, see p.7/p.8 item 8)
  • Page 16 Front panel audio connector This is an interface for front +5VA BACKOUT-R (9-pin AUDIO1) panel audio cable that allows BACKOUT-L convenient connection and (see p.7/p.8 item 20) control of audio devices. AUD-OUT-L AUD-OUT-R MIC-POWER System panel connector PLED+ This connector accommo-...

  • Page 17: Bios Setup

    Flash Memory on the motherboard stores the BIOS Setup Utility. When you start up the computer, there is a chance for you to run the BIOS Setup. Press <F2> during the Power-On-Self-Test (POST) to enter the BIOS Setup Utility, otherwise, POST continues with its test routines.

  • Page 18: Main Menu

    Enter:Select Sub-Menu System Date [Month/Day/Year] Set the system date that you specify. Valid values for month, day, and year are Month: (Jan to Dec), Day: (1 to 31), Year: (up to 2099). Use keys to move between the Month, Day and Year fields.
  • Page 19 “Secondary IDE Slave” to make configuration of its type. After making your selections on this sub-menu, press <ESC> key to return to the upper menu, in whcih the hard disk drive field will display the size of the hard disk drive that you configured. Below are the configuration options.

  • Page 20: Advanced, Security, Power, Boot, And Exit Menus

    LBA Mode This allows user to select the LBA mode for a hard disk > 512 MB under DOS and Windows; for Netware and UNIX user, select [Off] to disable the LBA mode.

  • Page 21: Software Support

    This motherboard supports various Microsoft Windows operating systems: 98 SE / ME / 2000 / XP. Because motherboard settings and hardware options vary, use the setup procedures in this chapter for general reference only. Refer to your OS documentation for more information.

  • Page 22: Appendix: Advanced Bios Setup

    ® ® ® ® such as Microsoft Windows XP. Set to [Auto] if using Microsoft Windows XP, or Linux kernel version 2.4.18 or higher. This option will be hidden if the current CPU does not support Hyper-Threading technology.
  • Page 23 AGP card requires other sizes. AGP Data Rate: The default setting is [Auto]. You may select between [8X] or [4X] for an AGP 3.0 card, or select among [4X], [2X], [1X] for an AGP 2.0 card.
  • Page 24 F10:Save & Exit Enter:Select Sub-Menu PCI Latency Timer (PCI Clocks): The default is 32. It is recommended to keep the default value unless the inserted PCI expansion cards’ specifications require other settings. Primary Graphics Adapter: This allows you to select [AGP] or [PCI] as the primary graphics adapter.
  • Page 25 OnBoard Serial Port: Use this to set addresses for the onboard serial ports or disable serial ports. Configuration options: [Auto], [Disabled], [3F8 / IRQ4 / COM1], [2F8 / IRQ3 / COM2], [3E8 / IRQ4 / COM3], [2E8 / IRQ3 / COM4]. OnBoard Infrared Port: You may select [Enable] or [Disabled] for this onboard infrared port feature.

  • Page 26: Security Menu

    Set User Password: Press <Enter> to set User Password. Valid password can be a 1 to 6 alphanumeric characters combination. If you already have a password, you must enter your current password first in order to create a new p assword.

  • Page 27: Power Menu

    Ring-In Power On: Use this to enable or disable Ring-in signals to turn on the system from the power-soft-off mode. PCI Devices Power On: Use this to enable or disable PCI devices to turn on the system from the power-soft-off mode.

  • Page 28: Boot Menu

    :Select Menu Enter:Select Sub-Menu Quick Boot Mode: Enable this mode will speed up the boot-up routine by skipping memory retestings. The default value is [Enabled]. Boot Up Num-Lock: If this is enabled, it will automatically activate the Numeric Lock function after boot-up. The default value is [On].

  • Page 29: Exit Menu

    BIOS Setup Utility without making any changes to the settings. Load Default Settings: After you enter the submenu, the message “Load default settings” will appear. If you press <Enter>, it will load the default values for all the setup configurations.
