✻ Before operating this unit, please read the instructions carefully.
✻ For indoor use only.
DJ68-00461W(0.5).indb 1
Vacuum Cleaner
user manual
imagine
the possibilities
Thank you for purchasing a Samsung product.
To receive a more complete service,
please register your product at
www.samsung.com/register
SC4530
English
2014. 2. 19.
11:26

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC4530 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Samsung SC4530

  • Page 1 ✻ Before operating this unit, please read the instructions carefully. English ✻ For indoor use only. imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register DJ68-00461W(0.5).indb 1 2014.
  • Page 2 safety information SAFETY INFORMATION • Before operating the appliance, please read this manual thoroughly and retain it for your reference. WARNING • Because these following operating instructions cover various models, the characteristics of your vacuum cleaner may differ slightly from those WARNING described in this manual.
  • Page 3 safety information IMPORTANT SAFEGUARDS 1. Read all instructions carefully. Before switching on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate on the bottom of the cleaner. 2. WARNING: Do not use the vacuum cleaner when rug or floor is wet. Do not use to suck up water.
  • Page 4: Table Of Contents

    contents ASSEMBLING THE CLEANER 05 Assembling the Cleaner OPERATING THE CLEANER 06 On/Off Switch 06 Power cord 07 Power control MAINTAIN TOOLS AND FILTER 08 Using accessory 09 Maintain floor tools 10 Emptying the dust bin 11 When to clean the dust pack 12 Cleaning the dust pack 13 Cleaning the motor protection filter 13 Cleaning the outlet filter...
  • Page 5: Assembling The Cleaner

    assembling the cleaner OPTION OPTION • Please do not press the button of dust bin handle when carrying machine. • For storage, park the floor nozzle. assembling the cleaner _5 DJ68-00461W(0.5).indb 5 2014. 2. 19. 11:26...
  • Page 6: On/Off Switch

    operating the cleaner ON/OFF SWITCH 1) BODY CONTROL TYPE 2) ON/OFF TYPE • When removing the plug from the electrical outlet, grasp the plug, not the cord. CAUTION POWER CORD 6_ operating the cleaner DJ68-00461W(0.5).indb 6 2014. 2. 19. 11:26...
  • Page 7: Power Control

    POWER-CONTROL 1) SLIDE CONTROL TYPE ONLY (OPTION) • SLIDE TO THE STOP POSITION Vacuum-cleaner switches off (stand by mode) • SLIDE FORWARD TO MAX Suction capacity increases smoothly up to maximum. 2) BODY-CONTROL TYPE / ON/OFF TYPE - HOSE To reduce suction for cleaning draperies, small rugs, and other light fabrics, pull the tap air until the hole is open.
  • Page 8: Using Accessory

    maintain tools and filter USING ACCESSORY PIPE (OPTION) • Adjust the length of the telescopic pipe by sliding the length control button located in the center of the telescopic pipe back and forth. • To check for blockages, separate the telescopic pipe and adjust to shorten.
  • Page 9: Maintain Floor Tools

    MAINTAIN FLOOR TOOLS 2-STEP BRUSH (OPTION) • Adjust the inlet lever according to the floor surface. • Remove waste matter completely if the inlet is blocked. Carpet Cleaning Floor Cleaning PET BRUSH (OPTION) For improved pick-up of pet hair and fibre on carpets. Frequent vacuuming of hair or pet fur may cause a falling-off of the rotation due to matters tangled around the drum.
  • Page 10: Emptying The Dust Bin

    maintain tools and filter EMPTYING THE DUST BIN Once dust reaches the dust full mark, or sution is noticeably reduced during Take the dust bin out by cleaning, empty the dust bin. pressing the button. Separate the dust bin cover. Before use, push the dust bin into the main body of the vacuum cleaner until you hear...
  • Page 11: When To Clean The Dust Pack

    maintain tools and filter WHEN TO CLEAN THE DUST PACK - If suction is noticeably reduced during cleaning, please check the dust pack as indicated below. Turn the vacuum power to 'MAX'. HANDLE CONTROL If suction is noticeably reduced with the inlet floating 10cm above flat floor, clean it.
  • Page 12: Cleaning The Dust Pack

    CLEANING THE DUST PACK 1. Remove the dust bin and dust pack as shown. 2. Remove the sponge and filter from the dust pack. 3. Wash the sponge and the filter of the dust pack with water. 4. Let the sponge and filter dry in the shade for more than 12 hours.
  • Page 13: Cleaning The Outlet Filter

    Remove and replace the blocked Press the fixed frame part at the outlet filter. back of the main body to remove. OPTION Replacement filters are available at your local Samsung distributor. maintain tools and filter _13 DJ68-00461W(0.5).indb 13 2014. 2. 19. 11:26...
  • Page 14 troubleshooting PROBLEM SOLUTION • Check cable, pulg and socket. Motor dows not start. • Leave to cool. Suction force is gradually • Check for blockage and remove. decreasing. • Pull the cord out 2-3m and push down the Cord does not rewind fully. cord rewind button.
  • Page 15 memo DJ68-00461W(0.5).indb 15 2014. 2. 19. 11:26...
  • Page 16 DJ68-00461W(0.5).indb 16 2014. 2. 19. 11:26...
  • Page 17 ✻ Antes de poner en funcionamiento la unidad, lea atentamente estas instrucciones. Español ✻ Sólo para uso en interiores. imagine the possibilities Gracias por adquirir un producto Samsung. Para recibir un servicio más completo, registre su producto en www.samsung.com/register DJ68-00461W(0.5).indb 1 2014.
  • Page 18 Información de seguridad INFORMACIÓN DE SEGURIDAD • Antes de utilizar el aparato, lea detenidamente este manual y conservélo para consultarlo en el futuro. Aviso • Puesto que las siguientes instrucciones de funcionamiento cubren varios modelos; las caracteristicas de su frigorifico pueden variar ligeramente de Aviso las descritas en este manual.
  • Page 19 Información de seguridad NOTAS IMPORTANTES SOBRE LA SEGURIDAD 1. Lea todas las instrucciones con cuidado. Antes de encender el aparato, asegúrese de que el voltaje de su instalación eléctrica corresponde con el indicado en la placa del régimen nominal de la parte inferior de la aspiradora. 2.
  • Page 20 Índice MONTAJE DEL ASPIRADORA 05 Montaje del aspiradora FUNCIONAMIENTO DEL ASPIRADORA 06 Interruptor ON/OFF 06 Cable de alimentación 07 Control de alimentación MANTENIMIENTO DE HERRAMIENTAS 08 Utilización de accesorios 09 Mantenimiento de herramientas para suelo Y FILTROS 10 Vaciado del cesto de recolección 11 Cuándo limpiar el filtro de esponja 12 Limpieza del filtro de esponja 13 Limpieza del filtro del motor...
  • Page 21 montaje del aspiradora OPCIONAL OPCIONAL • No presione el botón del depósito de polvo situado en el mango cuando transporte la máquina. • Para guardarlo, quite el accesorio para el suelo. montaje del aspiradora _5 DJ68-00461W(0.5).indb 5 2014. 2. 19. 11:26...
  • Page 22 funcionamiento del aspiradora INTERRUPTOR ON/OFF 1) CONTROL EN CARCASA 2) TIPO ON/OFF • When removing the plug from the electrical outlet, grasp the plug, not the cord. PRECAUCIÓN CABLE DE ALIMENTACIÓN 6_ funcionamiento del aspiradora DJ68-00461W(0.5).indb 6 2014. 2. 19. 11:26...
  • Page 23 CONTROL DE ASPIRACIÓN 1) SÓLO CONTROL CORREDIZO (Opcional) • COLOQUE EL ASPIRADORA EN LA POSICIÓN STOP El aspiradora se apaga (modo en espera). • COLOQUE EL ASPIRADORA EN MÁX. La capacidad de succión aumenta suavemente hasta el máximo. 2) CONTROL EN CARCASA / TIPO ON/OFF - TUBO FLEXIBLE Con el fin de reducir la aspiración de los trapos de limpieza, alfombrillas y otros tejidos ligeros, presione...
  • Page 24 manteni m i e nto de herrami e ntas y fil t ros UTILIZACIÓN DE ACCESORIOS PIPE (OPCIONAL) • Ajuste la longitud del tubo telescópico deslizando el botón de control de longitud situado en el centro del mismo como corresponda. •...
  • Page 25 MANTENIMIENTO DE HERRAMIENTAS PARA SUELO 2-STEP BRUSH (OPCIONAL) • Ajuste la palanca de admisión como corresponda • Retire los restos de para su limpieza. suciedad por completo si la entrada está obstruida. Limpieza de alfombras Limpieza de suelos PET BRUSH (OPCIONAL) Para mejorar la succión de pelo de animales y fibras sobre alfombras y moquetas.
  • Page 26 manteni m i e nto de herrami e ntas y fil t ros VACIADO DEL CESTO DE RECOLECCIÓN Cuando el polvo llegue a la marca indicadora de lleno de polvo o cuando se encienda el testigo de Saque el depósito de polvo Quite la cubierta del depósito polvo, vacíe el depósito de polvo.
  • Page 27 manteni m i e nto de herrami e ntas y fil t ros CUÁNDO LIMPIAR EL FILTRO DE ESPONJA - Si la succión se reduce de forma drástica durante la limpieza compruebe el compartimiento de recolección como se indica a continuación. Cambie la potencia de la aspiradora a ‘MAX’...
  • Page 28 LIMPIEZA DEL FILTRO DE ESPONJA 1. Retire el cesto y el compartimiento de recolección, como se muestra. 2. Retire la esponja y el filtro del colector de polvo. 3. Limpie la esponja y el filtro del compartimiento de recolección con agua. 4.
  • Page 29 Empuje el marco fijo de la parte obstruido. posterior de la aspiradora para extraer el filtro de salida. OPCIONAL Su distribuidor Samsung local cuenta con filtros de recambio. mantenimiento de herramientas y filtros _13 DJ68-00461W(0.5).indb 13 2014. 2. 19. 11:27...
  • Page 30 solución de problemas PROBLEMA SOLUCIÓN • Compruebe el cable, la clavija y la toma. El motor no se inicia. • Deje enfriarse. • Compruebe posibles obstrucciones y La potencia de succión disminuye poco a poco. extráigalas. • Saque el cable 2-3m y pulse el botón de El cable no se enrolla por completo.
  • Page 31 memo DJ68-00461W(0.5).indb 15 2014. 2. 19. 11:27...
  • Page 32 Contacte con SAMSUNG WORLD WIDE Si tiene alguna pregunta o comentario referente a nuestros productos, por favor contacte con nuestro Servicio de Atención al Cliente CONTACT CENTER ☎ COUNTRY WEB SITE ARGENTINE 0800-333-3733 www.samsung.com/ar DJ68-00461W-05 DJ68-00461W(0.5).indb 16 2014. 2. 19.
