PCB Piezotronics ICP 106C10 Installation And Operating Manual page 9

Model Number
106C10
Performance
Measurement Range(for ±2.5V output)
Sensitivity(± 20 %)
Maximum Pressure(step)
Maximum Pressure
Resolution
Resonant Frequency
Rise Time(Reflected)
Low Frequency Response(- 5 %)
Non-Linearity
Environmental
Acceleration Sensitivity
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Maximum Vibration
Maximum Shock
Electrical
Output Polarity(Positive Pressure)
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Physical
Sensing Geometry
Sensing Element
Housing Material 304/304L Stainless Steel
Diaphragm 316L Stainless Steel
Sealing
Electrical Connector 3-Pin MIL-C-5015
Weight
[3]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
ICP® PRESSURE SENSOR SPECIFICATIONS
EN GLISH SI
8.0 psi 55.1 kPa
300 mV/psi 43.51 mV/kPa
100 psi 690 kPa
200 psi 1,380 kPa
0.1 mpsi 0.00069 kPa
≥ 60 kHz ≥ 60 kHz
≤ 9.0 µ sec ≤ 9.0 µ sec
0.05 Hz 0.05 Hz
≤ 1.0 % FS ≤ 1.0 % FS
0.05 psi/g 0.035 kPa/(m/s²)
-65 to +250 °F -54 to +121 °C
≤ 0.05 %/°F ≤ 0.29 %/°C
1,000 g pk 1,000 g pk
2,000 g pk 19,620 m/s² pk
Positive Positive
≥ 10 sec ≥ 10 sec
12 to 30 VDC 12 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
3 to 8 VDC 3 to 8 VDC
Compression Compression
Quartz Quartz
304/304L Stainless Steel
316L Stainless Steel
Welded Hermetic Welded Hermetic
3-Pin MIL-C-5015
6.6 oz 187.0 gm
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
[1]
[2]
[1]
N OTES:
[1]Typical.
[2]Zero-based, least-squares, straight line method.
[3]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model 062M65 Adaptor, 1/2" NPT Thread and Clamp Nut (1)
Model 065M126 Secondary Ferrule, 0.680" OD x 0.438" ID x .0.288 THK Acetal (1)
Model 065M127 Primary Ferrule, 0.620" OD x 0.437 ID x 0.350" THK (1)
Model PCS-1 Calibration of dynamic pressure sensors at 100% full scale, max 15 kpsi range.
Entered: ND Engineer: AJA
Date: 05/29/2024 Date: 05/29/2024 Date: 05/29/2024 Date: 05/29/2024 9542
3425 Walden Avenue, Depew, NY 14043
Revision: D
ECN #: 54898
OPTION AL VERSION S
Sales: MV Approved: RPF Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
