Assembly Instructions
ECO Pedestal Assembly
Version 2.0
ECO Pedestal Assembly | 500 – 000027 – A
Item
Part Description
1
ECO Pedestal Drill Template
2
ECO Pedestal Base Assembly
4
ECO Pedestal Enclosure
5
ECO Pedestal Cover Plate
ECO Pedestal & CMS Universal Top
7
Bracket
8
ECO Top Cap Type - 2 Assembly
ECO Pedestal Fastener Kit | 504 – 000037 – A
Item
3
M12 Anchor Bolt
6
M10 x 20 mm, Universal Top Bracket Bolt
9
M6 x 60mm Tamper-Resistant Button Head Torx Screws
10
T30 - Tamper-Resistant Torx Screw L - Key
BlinkCharging.com • (888) 998.2546
Part Number
502 - 000045 - A
501 - 000031 - A
502 - 000032 - A
502 - 000062 - A
502 - 000033 - A
501 - 000054 - A
Fastener Description
Qty
1
1
1
1
1
1
Qty
4
2
2
1
