- Page 1 GALAXY AUTO MODEL: 3000 3100BX-EH PROFESSIONAL 12 GALLON AUTOMOTIVE DETAILER OWNER’S/OPERATOR’S MANUAL PROUDLY DESIGNED AND MANUFACTURED BY WWW.EDIC-USA.COM Revised 1-25-18...
-
Page 2: Table Of Contents
TABLE OF CONTENTS RECEIVING YOUR EQUIPMENT................... WARNINGS AND SAFETY....................ELECTRICAL INFORMATION..................GROUNDING INSTRUCTIONS..................MAINTENANCE........................ CORD STORAGE AND SAFETY..................MACHINE LAYOUT......................HEATER LAYOUT......................HOW TO USE AN ACCESSORY HEATER..............CLEANING CARPET......................CLEANING UPHOLSTERY....................TROUBLESHOOTING..................... WIRING..........................BREAKDOWN UPPER..................... 12, 13 BREAKDOWN BASE......................14, 15 WARRANTY INFO...................... -
Page 3: Receiving Your Equipment
Any deviation from its EDIC’s liability ceases when the carrier picks up the ship- proper use or purpose and the consequential damage ment. However, our customer service staff will be happy... -
Page 4: Electrical Information
GROUNDING INSTRUCTIONS FOR • All repairs must be done by an authorized EDIC repair station. 115VOLT: • Do not use replacement parts other than original EDIC parts. This piece of equipment must be grounded. Should an • Do not allow your spray stream to remain in one electrical malfunction occur, grounding provides a path fixed location as surface damage may occur. -
Page 5: Maintenance
MAINTENANCE: Weekly: This 3100BX-EH has been engineered and built to re- • Check and clean solution filter quire minimum maintenance. But like any machine, it • Check for obstructions in vacuum pathways does require some care to keep it in optimum working •... -
Page 6: Machine Layout
3100BX-EH MACHINE OVERVIEW 1. Handle- Used to maneuver and position the 3100BX- 6. Solution line Q.D.- Pressurized connection for solu- EH. Contains switch box (for switchbox, see #12). tion line. 2. Recovery tank and lid- Tank collects recovered waste 7. Male twist lock pigtail- Connects to 50ft power cord. water. -
Page 7: Heater Layout
602HR HEATER OVERVIEW 1. INLET QUICK DISCONNECT AND HOSE- Con- 5. OUTLET QUICK DISCONNECT- Connects to nects to machine’s outlet. working solution line. 2. POWER SWITCH. 6. HANDLE- Used to hold and transport the heater 3. LAMP- Indicates when heat element is on and work- 7. -
Page 8: How To Use An Accessory Heater
How to use the 602HR heater: 5. Connect your 15ft solution hose to #5 on page 7 1. Fill the solution tank of your 3100BX-EH extractor with sufficient water or solution for the task at hand. Do not use water over 130 degrees F. 2. -
Page 9: Cleaning Carpet
CLEANING UPHOLSTERY: off the pump and the heater. Attach the drain elbow on the drain valve. Place a pail under the downspout Cleaning upholstery with success requires a good knowl- and pull up the drain valve T-handle. Dirty solution edge of the type of fabric to be worked on. Look for the will pour out until the tank is empty. -
Page 10: Troubleshooting
ELECTRICAL SYSTEM PROBLEM SOLUTION NO ELECTRICAL POWER 1. Defective power cord. 2. House or building circuit breaker tripped POWER IS INTERMITTENT TO ONE OR ALL MO- 1. Faulty electrical cable. TORS 2. Defective switches. 3. Loose terminal or discolored terminal connections. VACUUM SYSTEM PROBLEM SOLUTION... -
Page 11: Wiring
3100BX-EH 4-26-16 HANDLE MOTOR HOUSING BLACK WHITE HEATER RECEPTACLE... -
Page 12: Breakdown Upper
11 12 13 14 15 ITEM 3100BX-EH UPPER 4-27-16... - Page 13 3100BX-EH UPPER 4-27-16 ITEM PART NUMBER DESCRIPTION QTY. F11794 Solution Tank F11788 Recovery Tank F11791 Lid, Solution Tank E11124 Gasket, Recovery Tank 12904A Stand Pipe Assembly K11965 Elbow, 180 Deg. Float Ball K00672 Pvc Pipe, 1.5 X 12 in, Sch 40 Wht 10989-2A Float Ball Screen K00741 Adapter F11785 Lid, Recovery Tank...
-
Page 14: Breakdown Base
20 21... - Page 15 ITEM PART NUMBER DESCRIPTION QTY. C00297 Screw,#8 X .25 in, Pan Head J11863 Hose, 3 in J00639 Screw Clamp, 1.63 - 2.43in. J00618 Vacuum Hose, 2in Grey, Wire, 22 in lg F11178-BLK Intercooler, Galaxy, Black C00273 Locknut, 1-4 X 20, Nylon, SS C00233 Washer, Flat, .25 in E00449 Grommet C00284 Screw, 10-32 X .375 Ground...
-
Page 16: Warranty Info
Standard Rates, during the warranty period set forth above. This warranty excludes transportation charges unless authorized in writing by EDIC. No warranty returns for refund or credit will be permitted. In the event of a defect, these are your exclusive remedies. Warranty claims must be made in writing to EDIC prior to returning the product and no products will be accepted for repair or replacement without prior authorization by EDIC. - Page 17 (f) acts of God; or (g) modification of or any part of the product. This Limited Warranty does not cover EDIC products sold AS IS and WITH ALL FAULTS. This Limited Warranty is valid only in the United States and Canada.
