Stone Mountain BluSkye® Bluetooth®
Speaker Microphone (SM) User Manual
BluSkye® is a feature rich, industrial grade Bluetooth®
speaker microphone that supports Android, iOS,
Windows and LMR platforms running Push To Talk
(PTT) applications.
Starting Out
1. Charge the SM for at least six (6) hours prior to
first use. When the SM is powered off, there is
no LED charging indication, though charging is
still occurring. Note: Be sure to only charge
with Stone Mountain approved charging
accessories.
Button
Primary Function
1
SW1
Emergency/programmable
2
SW2
PTT
3
SW3
RampClik™ volume control
Programmable button (e.g. message
4
SW4-P
replay, etc.)
5
SW5-P
Phone call control
6
SW6
On/off, pairing, etc.
Tac10™ rotary channel select
7
SW7
(optional)
8
3.5mm Rx audio port
9
TruDock™ cradle contacts
10
5.5mm charging port
11
LED indicator
12
QuickPair™ NFC pairing location
Notes
1. Buttons may have different functions depending upon the PTT app. Refer to your PTT app and/or device user
manual for further details.
2. To toggle between Primary (P) Function and Secondary (S) Function, press and hold SW3, then immediately
press and hold SW4. An audible beep identifies which Function is active as follows:
One beep: Primary Function is active.
Two beeps: Secondary Function is active.
3. QuickPair™ requires an Android device equipped with NFC. QuickPair™ is not available for iOS.
Stone Mountain, Ltd.
1597 Eagle Point Road
Huddleston, VA 24104
Innovation... Quality... Passion
Button
SW4-S
SW5-S
Effective 17Apr24
Secondary Function
Notes
Note 1
Channel down
Note 1 & 2
Channel up
Note 1 & 2
Note 3
Customer Support: 540.297.6434 x200
www.stonemountainltd.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the BluSkye and is the answer not in the manual?

Questions and answers

Summary of Contents for Stone Mountain BluSkye

  • Page 1 Innovation… Quality… Passion Stone Mountain BluSkye® Bluetooth® Speaker Microphone (SM) User Manual BluSkye® is a feature rich, industrial grade Bluetooth® speaker microphone that supports Android, iOS, Windows and LMR platforms running Push To Talk (PTT) applications. Starting Out 1. Charge the SM for at least six (6) hours prior to first use.
  • Page 2 Place the SW4 and SW5 flush/close to the NFC reader on your device. Select “Pair” when the message “Pair with BluSkye BT?” appears. Allow up to 10 seconds for the device to recognize the SM. Traditional Pairing: With the microphone turned off, press and hold SW6 for six (6) seconds. An audible booBEEP followed by a beeBEEP means the unit is in pairing mode.
  • Page 3 TruDock™ Remote Charging, Tx & PTT BluSkye® comes standard with remote cradle charging. Remote Tx and PTT is available as an option. You can purchase TruDock™ cradles and HanzFree™ accessories that transform your SM into a 100% hands free charging and communication system.
