Stone Mountain BluSkye User Manual

Stone Mountain BluSkye® Bluetooth®
Speaker Microphone (SM) User Manual
Rev. BS-OM-A3
BluSkye® is a feature rich, industrial grade Bluetooth®
speaker microphone that supports Android, Windows
and LMR platforms running Push To Talk (PTT) applications.
SM buttons may have different assigned functions by the PTT
OEM than those shown below – Read your PTT application
and/or Device manual for further information.
Starting Out
1. Charge the SM for at least six (6) hours prior to
first use. When the SM is powered off, there is
no LED charging indication, though charging is
still occurring. Note: Be sure to only charge
with Stone Mountain approved charging
accessories.
Notes
1. Buttons may have different functions depending upon the PTT app. Refer to your PTT app and/or Device user
manual for further details.
2. Function dependent upon configuration.
1.0 Basic Operating Instructions
1.1
Power On: While the unit is off, press and hold SW6 for three seconds. A low-mid two-tone beep and two
blue LED flashes will occur powering on the Device.
Stone Mountain, Ltd.
1597 Eagle Point Road
Huddleston, VA 24104
Innovation... Quality... Passion
Button Primary Function
1 SW1 Emergency/programmable
2 SW2 Primary PTT
3 SW3 RampClik™ volume control
Programmable button (e.g. message
4 SW4
replay, phone call control, etc.)
5 SW5 Not used/no function
6 SW6 On/off, pairing, configuration, etc.
7 3.5mm Rx Audio Port
TM
8 TruDock
9 5.5mm charging port
10 LED indicator
Effective 05Jul23
23
cradle contacts
Notes
Note 1
Note 1, 2
