- Page 1 Prestel EHD-PLE HDMI over Power Extender with one-way IR USER MANUAL...
-
Page 2: Table Of Contents
Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
1. Introduction This power extender is based on H.265 standard solution for distribution 1 HD source to 3 HD displays simultaneously via power line transmission within the scope of one electricity meter, and supports one-way IR control. It offers high quality video and supports resolution up to 1080P@60Hz. In addition, one HDMI loop port of encoder is available for output. -
Page 4: Specifications
4. Specifications Technical HDMI Compliance HDMI 1.3 HDCP Compliance HDCP 1.4 Video Bandwidth 6.75Gbps 1080p, 1080i, 720p, 720i, 480p, 480i, the maximum Video Resolution up to 1920×1080@60Hz The PC resolution is up to 1400×1050 Color Space RGB/YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0 Color Depth 8/10/12-bit HDMI Audio Formats... -
Page 5: Operation Controls And Functions
Resolution / 1080P@60Hz - Cable Length Feet / Meters HDMI IN / OUT 42ft / 15M The use of “Premium High Speed HDMI” cable is highly recommended. 5. Operation Controls and Functions 5.1 Encoder Panel POWER LINK RESET HDMI over Power Extender HDMI OUT HDMI IN IR OUT... -
Page 6: Decoder Panel
5.2 Decoder Panel POWER LINK RESET HDMI over Power Extender HDMI OUT IR IN AC/220V Name Function description POWER LED Red LED indicates that the decoder is powered. LINK LED ■ Flicker slowly: No pair. (Green) ■ Flicker quickly: Paired success. ■... -
Page 7: Ir Pin Definition
5.3 IR Pin Definition IR Receiver and Blaster pin’s definition as below: IR RECEIVER IR BLASTER IR Blaster IR Blaster Signal Power IR Receiver IR Signal Power Grounding 5 / 7... - Page 8 IR use example: DVD Remote Power transmission HDMI OUT HDMI IN IR OUT HDMI OUT IR IN AC/220V AC/220V Encoder Decoder Note that IR remote sends signal distance for 0~5 meters / 0~8 meters, and angle is plus-minus 45 degrees / vertical direction . 6 / 7...
-
Page 9: Application Example
6. Application Example 0 0 0 9 6 8 Electricity meter Power transmission Decoder HDMI OUT IR IN AC/220V Encoder DVD remote HDMI OUT IR IN AC/220V HDMI OUT HDMI IN IR OUT AC/220V Decoder DVD remote HDMI OUT IR IN AC/220V Decoder DVD remote...
