Article
Green Pin® Connecting link
(U)MJ(I)
Subject
Instructions for use – Green
Pin® Connecting link
(U)MJ(I)
Date
23-9-2014
Ref
PI-03-07 EN
Revision
0
MJ
UMJ
MJI
Frequently Asked Questions
Subject: Instructions for use – Green Pin® Connecting link (U)MJ(I)
Note: Main dimensions, general info and warnings can be found in
our latest catalogue.
Green Pin® Connecting link
Follow the steps hereunder to assemble several eye type fitting,
master links and chain to each other.
Make sure you have all the correct components to assemble the chain
sling.
After inserting of the two half links in the components to be connected
with, the bush will be positioned between the two half links.
The pin must be driven trough the parts with a hammer.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Van Beest GreenPin MJ
Summary of Contents for Van Beest GreenPin MJ
- Page 1 Frequently Asked Questions Subject: Instructions for use – Green Pin® Connecting link (U)MJ(I) Note: Main dimensions, general info and warnings can be found in our latest catalogue. Article Green Pin® Connecting link Follow the steps hereunder to assemble several eye type fitting, Green Pin®...
- Page 2 Make sure the pin is completely assembled into the connecting link The pin is kept in place by the bush. Check the correct position (half links, pin, bush) and the locking of the components. Make sure the connecting link (both half links) can hinge freely. Refer to the standard EN 818-4 (chain sling) before using.
- Page 3 Do not fit two loaded chains in the same half connecting link. It is only allowed when shortening clutches or shortening hooks are used and only one of these two legs is loaded. If you have further questions, please do not hesitate to contact us. Kind regards, Van Beest Product Management...
