- Page 1 Instructions for use FKI Clamshell Grill STD 9001/9002/9003 Type code: ACS-24 Version 2.0...
-
Page 2: Table Of Contents
Contents Introduction ............................... 4 General .............................. 4 Appliance description ........................4 Manufacturer ..........................4 Appliance label ..........................5 Technical specifications and power consumption ............... 5 Modification ..........................6 Dimensions ..........................6 Safety ................................. 7 Personal safety equipment ........................ 7 Potential hazards ..........................7 Who may use the appliance ...................... - Page 3 Eco mode ............................16 Settings ............................17 Top pan ............................17 Bottom pan ............................17 Volume............................. 18 Duration of buzzer sound ........................ 18 The programmes ..........................19 Software version ..........................20 Factory settings ..........................20 Error codes............................22 Spare parts ............................23 Wiring diagram ............................
-
Page 4: Introduction
1 Introduction Original user instructions These instructions are FKI Fast Food Teknik's original instructions for the appliance CLAMSHELL GRILL. The purpose of these instructions These instructions are intended to ensure the correct installation, use, handling and maintenance of CLAM- SHELL GRILL. -
Page 5: Appliance Label
Height when open: 920 mm Weight: 96 kg. 1.1.4.2 Power Theoretical consumption per phase* Product Voltage Fusion Power 400V 3N~ Clamshell Grill STD 9001 230V 3~ 400V 3N~ Clamshell Grill STD 9002 14kW 230V 3~ 400V 3N~ Clamshell Grill STD 9003 10kW 230V 3~ *Actual measured result can be expected to be lower. -
Page 6: Modification
CLAMSHELL GRILL must only be used to fry food. Modification CLAMSHELL GRILL must never be modified or serviced by unauthorised persons. In the event of non-compli- ance, FKI Fast Food Teknik a/s waivers any and all liability. Dimensions Clamshell Grill STD 9001... -
Page 7: Safety
These instructions and the appliance itself are provided with important safety information that must always be read and observed at all times. FKI Fast Food Teknik a/s disclaims any and all liability for non- compliance with these safety instructions, for inappropriate use of the appliance or the use of incorrect set- tings. -
Page 8: Transport/Installation/Fixation
This appliance is not intended for use by children! Neither should it be used by persons with re- duced physical or mental capacity, or who lack appropriate experience and knowledge unless they have been trained or instructed in the use of the appliance by someone with responsibility for their safety. -
Page 9: Installation
Installation Set up the Clamshell Grill on a counter or similar at a suitable working height (We recommend a counter height of 65 cm to achieve a working height of 90 cm). The counter on which the Clamshell Grill is set up must be approved for the appliance's weight plus 25% and must not be able to tip over when using the appliance. -
Page 10: Fixation
Any replacement of the power cord must be performed by an authorised technician to avoid the risk of personal injury – RISK of electric shock. Only use oil-resistant cables! Fixation The appliance does not need to be secured. It is equipped with adjustable legs to ensure stable and easy installation. -
Page 11: Servicing
Accessories Teflon film: Only original FKI Fast Food Teknik a/s Teflon foil may be used on the CLAMSHELL GRILL. This foil must not be used on other appliances. Teflon foil part number: 01-10104 –... -
Page 12: Operation
3 Operation Before first use Before start-up, remove all packaging and protective plastic from the Clamshell Grill and dispose of it in accordance with currently applicable regulations (see section 8.1). Carefully read section2 about safety before connecting the Clamshell Grill. Before start-up, clean the appliance as shown in section 6. -
Page 13: Start-Up
Start-up The machine is switched on at the main switch located at the back of the machine. Adjustment The distance between the upper and lower pan should be adjusted to suit the thickness of the meat. The distance is infinitely adjustable between 5 and 25 mm by turning the adjustment lever on top of the support arm at the top pan. -
Page 14: Quick Guide
4 Quick guide Introduction This quick guide describes how the user interface works. Standby Figure 1, standby mode When the appliance is switched on at the main switch, it is possible to start it by pressing , see section Active. Set up the appliance by pressing , see section Settings. -
Page 15: Active
Active To start the appliance, press when the appliance is in standby, see section Standby. Figure 2, active mode showing the temperature setpoint for the bottom pan at 225°C. When the appliance is active, the appliance will heat up and the temperature setpoint for the bottom pan will be displayed. -
Page 16: Select Eco Mode
If the programme is set to anything other than zero seconds, the programme will count down to zero. Then the pan will rise, and a buzzer will sound according to the settings. If the programme is set to zero, the pro- gramme will count up. -
Page 17: Settings
When the appliance is in Eco mode, it is possible to cancel the mode by pressing , and the appliance will return to active mode. It is possible to put the appliance in standby mode by pressing . This will cause the pan to rise and the heat to turn off. -
Page 18: Volume
Press , to move on to the next setting. If numbers are flashing, settings have been changed and saved in the appliance. If they are not flashing, the appliance has not registered any changes. Figure 7, setting the bottom pan. Volume To see the current setting of the volume, press either . -
Page 19: The Programmes
Press , to move on to the next setting. If numbers are flashing, settings have been changed and saved in the appliance. If they are not flashing, the appliance has not registered any changes. Figure 9, setting the duration of the buzzer sound. The programmes To see the current setting for a given programme, press the desired programme, 1 to 6. -
Page 20: Software Version
recalling the 160 seconds programme, you only need to press , twice to change the programme to 150 seconds. The same applies to 170, but with the use of If a programme is set to zero seconds, the programme will count up in active mode. This can be useful if new products are introduced and the optimal time is unknown. - Page 21 Figure 13, restoring factory settings. Press to exit the setting mode and return to standby mode.
-
Page 22: Error Codes
Error codes Error code chart ERROR CODE ERROR CAUSE REMEDY Undefined error Unknown Contact service. Temperature sensor fault on The measured values are too The surroundings are either top pan low compared to those ex- too cold or the sensor is pected. -
Page 23: Spare Parts
Spare parts Spare parts diagram Clamshell Grill STD 9001 PRODUCT DESCRIPTION NUMBER 72-05529 FOIL FOR CLAMSHELL STD 9001 83-09056 TRANSFORMER 240V/12V 3VA 83-10316 SOLID STATE RELAY 20-265VAC/VDC 24-510V 50A 83-07563 RECTIFIER GBPC25005-E4 83-10016 TRAFO,RING-2x24/230V 120VA 83-07680 TERMINAL BLOCK 4-POLE 83-07681... - Page 24 Spare parts diagram Clamshell Grill STD 9002 PRODUCT NUMBER DESCRIPTION 72-05528 FOIL FOR CLAMSHELL STD 9002/9003 83-09056 TRANSFORMER 240V/12V 3VA SOLID STATE RELAY 20-265VAC/VDC 24-510V 83-10316 83-10016 TRAFO,RING-2x24/230V 120VA 83-09210 SCREEN PLATE GL9002 BOTTOM 83-03499 CLAMP GL6036 / 6046 / 3060 Heat element and PT100 sensor see component list under electrical diagram Heat element and PT100 sensor...
- Page 25 72-08011 CONTROL CLAMSHELL STD Spare parts diagram Clamshell Grill STD 9003 PRODUCT NUMBER DESCRIPTION 72-05528 FOIL FOR CLAMSHELL STD 9002/9003 83-09056 TRANSFORMER 240V/12V 3VA 83-10316 SOLID STATE RELAY 20-265VAC/VDC 24-510V 50A 83-07563 RECTIFIER GBPC25005-E4 83-10016 TRAFO,RING-2x24/230V 120VA 83-09312 CLAMP GL9001 LOWER LARGE 83-09119 SCREEN PLATE GL8001/-2/9001/3 BOTTOM LARGE Heat element and PT100 sensor...
- Page 26 83-07680 TERMINAL BLOCK 4-POLE...
-
Page 27: Wiring Diagram
5 Wiring diagram Component list... -
Page 28: Electrical Diagram
Electrical diagram... -
Page 31: Cleaning
6 Cleaning General Before using the appliance for the first time, wipe all surfaces that will be in contact with food with a damp cloth. Do not use cleaning products that contain acid. Cleaning during operation After each fry, first scrape the top pans and then scrap all grease from the bottom pan into the grease trays. -
Page 32: Service
7 Service Find out if it is possible to correct the fault by following the instructions in the troubleshooting chart. If not, contact your dealer or www.fki.dk for assistance. When contacting service for assistance, please have the following information ready: •... - Page 33 To make it easy to service a CLAMSHELL GRILL, most electrical parts are mounted in a drawer system that can be pulled out at the front. For access, remove two screws under the front section, which will allow the drawer to be pulled out. When removing the back plate/guard at the actuator and servicing the mechanical parts, there may be a risk of trapping, be careful with the moving parts.
-
Page 34: Disposal
8 Disposal Packaging The packaging should not be left in the environment but should be disposed of in accordance with local regulations. When the appliance is no longer required CLAMSHELL GRILL is labelled with a recycling symbol in accordance with Executive Order 148 of 8 February 2018 (Electronic Waste Executive Order/Elektronikaffaldsbekendtgørelsen). -
Page 35: Eu Declaration Of Conformity
9 EU DECLARATION OF CONFORMITY... - Page 36 Byghøjvej 5 · Verninge · DK-5690 Tommerup · Denmark · Tel. +45 6475 1066 · info@fki.dk · www.fki.dk...
