Sorenson ntouch VP2 Quick Help

Hide thumbs Also See for ntouch VP2:

Advertisement

Quick Links

Download this manual
QuickHelp
Calling Features
Use the bookmarks in the left-hand column to jump to the QuickHelp answers to these questions:
How do I use the Group Call feature?
How do I set up Voice Carry Over (VCO) calling?
How do I show the in-call audio level meter?
How do I change how long the options bar appears when a call starts?
How do I change my Self-View image video settings during a call?
How do turn the Do Not Disturb mode on and off?
How do I use the Group Call feature?
You can use the Group Call feature to have a conversation with up 4 other people at one
time. A group call begins when you "join" two calls together into one call. You can then
add up to 2 other calls (for a total of 4 calls) at once. You can use the ntouch VP2 Group
Call feature with all Sorenson endpoints during a point-to-point call. The Group Call
feature does not work with Sorenson Video Relay Service (SVRS) calls.
The example images below show the Video Privacy mode enabled on all endpoints. This
was done to make it easier to see how to use the feature.
Step 1.
When in an active call, press the
options bar as shown below.
In-call options bar
Step 2.
Move to the
Call button
OK
Call
button as shown below.
Sorenson ntouch VP2
key on the remote control to open the In-call

Advertisement

loading
Need help?

Need help?

Do you have a question about the ntouch VP2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sorenson ntouch VP2

Summary of Contents for Sorenson ntouch VP2

  • Page 1 A group call begins when you “join” two calls together into one call. You can then add up to 2 other calls (for a total of 4 calls) at once. You can use the ntouch VP2 Group Call feature with all Sorenson endpoints during a point-to-point call. The Group Call feature does not work with Sorenson Video Relay Service (SVRS) calls.
  • Page 2 Step 3. Select the Call button to open the Call menu as shown below. Call menu open You can choose to make a call from your Call History list, Favorites list, Phonebook Contacts list or dial a number using the on-screen keypad. Step 4.
  • Page 3 Step 7. Press the key on the remote control to open the In-call options bar as shown below. In-call options bar Step 8. Move to the Join button as shown below. Join button Step 9. Select the Join button to join the calls as shown below. Joining calls message Step 10.
  • Page 4 Step 11. After the calls are joined, you will see the received video images from both calls appear in the center of the screen as shown below. 1st Received image 2nd Received image Step 12. To add more calls to the Group Call, repeat Steps 1 through 10 above.
  • Page 5 How do I set up Voice Carry Over (VCO) calling? Step 1. Start at the Home screen as shown below. Settings button Step 2. Select the Settings button to open the screen shown below. Call Options button selected Step 3. Select the Call Options button to open the screen shown below.
  • Page 6 Step 5. Move to and select the Voice Carry Over checkbox as shown below. Turn on Voice Carry Over (VCO)? checkbox VCO audio choices radio buttons Selecting the Turn on Voice Carry Over (VCO)? checkbox reveals the VCO audio choices radio buttons. You can use either 1-line VCO or 2-line VCO. If you select 2-line VCO, you must enter a call back phone number of the voice telephone you will be using.
  • Page 7 How do I show the in-call audio level meter? Step 1. Start at the Home screen as shown below. Settings button Step 2. Select the Settings button to open the screen shown below. Call Options button selected Step 3. Move to the Device Options button as shown below.
  • Page 8 Step 5. Move to the Sound button to open the screen shown below. Sound button Step 6. Move to and select the Use point-to-point audio checkbox as shown below. Use point-to-point audio? checkbox Selecting the Use point-to-point audio? checkbox reveals the Show audio meter? radio button.
  • Page 9 How do I change how long the options bar appears when a call starts? Step 1. Start at the Home screen as shown below. Settings button Step 2. Select the Settings button to open the screen shown below. Call Options button selected Step 3.
  • Page 10 How do I change my Self-View image video settings during a call? Step 1. When in an active call, press the key on the remote control to open the In-call options bar as shown below. Self-View image In-call options bar Step 2.
  • Page 11 Step 4. Select the Zoom & Pan button to open the controls shown below. Zoom and Pan controls • Use the Zoom control to zoom the camera image in and out. • Press the key on the remote control to move between the Zoom and Pan controls.
  • Page 12 How do turn the Do Not Disturb mode on and off? Step 1. Start at the Home screen as shown below. Settings button Step 2. Select the Settings button to open the screen shown below. Step 3. Move to the Do not disturb button as shown below.
  • Page 13 Step 5. Select the button to turn on the Do Not Disturb mode. When you return to the Home screen, its appearance will have changed as shown below. Notice that the top area of the Home screen now shows a diagonal pattern and the “Do not disturb;...
