QuickHelp
Hardware Features
Use the bookmarks in the left-hand column to jump to the QuickHelp answers to these questions:

How do I use the HDMI Pass-Through feature?

How do I use the HDMI Pass-Through feature?
The HDMI Pass-Through feature lets you connect external devices, such as a DVD or
Blu-Ray player, HD Cable TV set-top box, or HD Satellite TV set-top box to the
HDMI-In port on the back of the ntouch VP2 Main Unit. You will need an HDMI Type
A Male-to-Type D (Micro) Male connector plug to make this connection.
The external device connected to ntouch VP2 must be able to generate a constant output
signal of 720p/60, 1080p/60 or 1080p/24 (Blu-Ray movie) "progressive" resolution for
the HDMI Pass-Through feature to work properly. The "interlaced" 1080i resolution is
not supported by ntouch VP2.
After you have connected the external device to the ntouch VP2's HDMI In port, you can
switch back and forth between the videophone display and the external device display.
Step 1.
Connect a Male Type A-to-Mail Type D HDMI cable to ntouch VP2's HDMI In port.
The back panel of the ntouch VP2 Main Unit is shown below.
Step 2.
Look for the
Switch to TV button
Switch to TV
button on ntouch VP2's Home screen as shown below.
Sorenson ntouch VP2
HDMI In port (Micro Type-D)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ntouch VP2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sorenson Ntouch VP2

Summary of Contents for Sorenson Ntouch VP2

  • Page 1 Blu-Ray player, HD Cable TV set-top box, or HD Satellite TV set-top box to the HDMI-In port on the back of the ntouch VP2 Main Unit. You will need an HDMI Type A Male-to-Type D (Micro) Male connector plug to make this connection.
  • Page 2 If you do not see the Switch to TV button on the Home screen as shown above, either there is no signal coming from the external device, or the signal that is being sent is not supported by ntouch VP2. Check to make sure your external device is set to output a constant 1080p or 720p resolution.
  • Page 3 What do the two icons on the front side of the camera mean? Step 1. Look at your ntouch VP2’s remote camera unit as shown below. New SignMail LED Missed Call LED There are two icons printed on the front surface and two LEDs next to the icons. The LED next to the envelope icon will be turned on if you have new SignMail video messages.
  • Page 4 Front side of main unit Status LED The Status LED on the right-front side of the ntouch VP2 main unit will change colors indicate the videophone’s status, both during and after the booting (start-up) process. The normal LED sequence (i.e., no problems encountered during booting) is: Light Green—Amber—Green—Amber—Green...
  • Page 5 Look at the top-side surface of your ntouch VP2’s main unit as shown below. Top side of main unit Handset and Arrow buttons The Handset and four Arrow buttons on the top side of the ntouch VP2 main unit can be used to place a call without using the remote control. Step 2.
