QuickHelp
Bluetooth and Networking Features
Use the bookmarks in the left-hand column to jump to the QuickHelp answers to these questions:
How do I connect a Bluetooth keyboard to my ntouch VP2?
How do I change my network connection from Wired to Wireless?
How do I use the HDMI Pass-Through feature?
How do I connect a Bluetooth keyboard to my ntouch VP2?
You can connect Bluetooth keyboards to your ntouch VP2. Sorenson has confirmed that
these keyboards work with ntouch VP2: Logitech K480 and K380, B-Typer BK-310,
Apple Keyboard MC184LL/B, SPARIN Mini Bluetooth Keyboard, SIG 02-1720A.
Step 1.
Start at the Home screen as shown below.
Settings button
Step 2.
Select the
Device Options button
Step 3.
Select the
Settings
button to open the screen shown below.
Device Options
button to open the screen shown below.
Sorenson ntouch VP2
Advertisement
Related Manuals for Sorenson ntouch VP2
Summary of Contents for Sorenson ntouch VP2
- Page 1 How do I use the HDMI Pass-Through feature? How do I connect a Bluetooth keyboard to my ntouch VP2? You can connect Bluetooth keyboards to your ntouch VP2. Sorenson has confirmed that these keyboards work with ntouch VP2: Logitech K480 and K380, B-Typer BK-310, Apple Keyboard MC184LL/B, SPARIN Mini Bluetooth Keyboard, SIG 02-1720A.
- Page 2 Scan for devices... button as shown below. Scan for devices... button Step 8. Put your Bluetooth device into its “pairing” (or “connect”) mode before continuing. Your ntouch VP2 will not be able to detect the device unless it is ready to pair.
- Page 3 Step 9. Select the Scan for devices... button to begin the scan as shown below. Searching for devices... message Step 10. When the scan is completed, you will see a message like the one shown below. Found devices list This example shows one keyboard (a Logitech K480) was detected by the videophone. Step 11.
- Page 4 Step 13. On the Bluetooth keyboard, type the characters shown in the dialog to complete the pairing process and display the screen shown below. List of paired devices Green checkmark shows device is connected The right side of the screen now shows a list of Saved/Paired Bluetooth devices. The green checkmark next to the device name shows that the device is currently connected.
- Page 5 How do I change my network connection from Wired to Wireless? Step 1. Start at the Home screen as shown below. Settings button Step 2. Select the Settings button to open the screen shown below. Network/Admin button Step 3. Select the Network/Admin button to open the screen shown below.
-
Page 6: Edit Button
Step 5. Select the Wireless button to begin a scan for wireless networks. The available networks (those within range) will appear in a list as shown below. List of available networks The network names in this sample image all have two-character names such as “B9.” You should only connect to known, secured networks (i.e., you own wireless router). - Page 7 Step 9. Select the Done button to return to the dialog shown below. Done button Step 10. Select the Done button to send the password and attempt to connect to the wireless network. If successful, you will see the screen shown below. Green checkmark shows network is connected The green checkmark next to the network name shows that the videophone is currently...
- Page 8 Blu-Ray player, HD Cable TV set-top box, or HD Satellite TV set-top box to the HDMI-In port on the back of the ntouch VP2 Main Unit. You will need an HDMI Type A Male-to-Type D (Micro) Male connector plug to make this connection.
- Page 9 VP2 will display the dialog shown below when an incoming call is received. The dialog is displayed over the video image from the external device. Image from external device Incoming call dialog You can also switch back to the ntouch VP2 display by turning off the external device.
