PCB Piezotronics ICP 137B21X Installation And Operating Manual page 8

Model Number
137B21B
Performance
Measurement Range(for ±1V output)
Sensitivity(± 15 %)
Maximum Pressure
Resolution
Resonant Frequency
Rise Time(Incident)
Non-Linearity
Environmental
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Electrical
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Physical
Sensing Geometry
Sensing Element
Housing Material
Diaphragm
Sealing
Electrical Connector
Weight
[3]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
ICP® PRESSURE SENSOR
EN GLISH SI
1 kpsi 6,895 kPa
1 mV/psi .145 mV/kPa
5 kpsi 34,474 kPa
8.5 mpsi .059 kPa
≥ 400 kHz ≥ 400 kHz
≤ 6.5 µ sec ≤ 6.5 µ sec
≤ 1.0 % FS ≤ 1.0 % FS
-100 to +275 °F -73 to +135 °C
≤ 0.05 %/°F ≤ 0.090 %/°C
≥ 0.2 sec ≥ 0.2 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
Compression Compression
Quartz Quartz
Aluminum Aluminum
Invar Invar
Epoxy Epoxy
BNC Jack BNC Jack
12.4 oz 352 gm
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
[1]
[2]
[1]
N OTES:
[1]Typical.
[2]Zero-based, least-squares, straight line method.
[3]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model PCS-1 Calibration of pressure sensors up to 15k psi (except Series 113B50)
Entered: LK Engineer: RPF
Date: 11/13/2020 Date: 11/13/2020 Date: 11/13/2020 Date: 11/13/2020 55316
3425 Walden Avenue, Depew, NY 14043
Revision: B
ECN #: 51260
OPTION AL VERSION S
Sales: RWM Approved: RPF Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
