ASROCK K10N78D Specifications

K10N78D
®
NVIDIA nForce 720D Chipset
Product Brief
- Supports for AM3 / socket AM2+ / AM2
processors
- Gigabit LAN
- 7.1 CH Windows ® Vista™ Premium Level
®
HD Audio (VIA VT1708S Audio Codec with
QSound)
- Supports ASRock Instant Boot, Instant Flash,
OC Tuner, Smart BIOS, Intelligent Energy Saver
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
w ww.as rock.com
Detail Specification
- ATX Form Factor: 12.0-in x 7.5-in, 30.5 cm x 19.1 cm
Platform
- Solid Capacitor for CPU power
CPU - Support for Socket AM2+ / AM2 processors: AMD
Phenom TM FX / Phenom / Athlon 64 FX / Athlon 64 X2
Dual-Core / Athlon X2 Dual-Core / Athlon 64 / Sempron
processor
- Support for AM3 processors: AMD Phenom
and Athlon II X4 / X3 / X2 processors
- AMD LIVE! TM
- Supports AMD's Cool 'n' Quiet Technology
- FSB 2600 MHz (5.2 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport 3.0 (HT 3.0) Technology
Chipset - NVIDIA ® nForce 720D
- Dual Channel DDR2 memory technology
Memory
- 4 x DDR2 DIMM slots
- Supports DDR2 1066/800/667/533 non-ECC,
un-buffered memory
- Max. capacity of system memory: 16GB
- 1 x PCI Express 2.0 x16 slot (green @ x16 mode)
Expansion Slot
- 3 x PCI Express x1 slots
- 3 x PCI slots
Audio - 7.1 CH Windows
(VIA ® VT1708S Audio Codec)
LAN - Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Realtek RTL8211CL
- Supports Wake-On-LAN
I/O Panel
Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Coaxial SPDIF Out Port
- 1 x Optical SPDIF Out Port
- 6 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
- HD Audio Jack: Side Speaker / Rear Speaker / Central /
Bass / Line in / Front Speaker / Microphone
Connector - 6 x SATAII 3.0 Gb/s connectors, support RAID (RAID 0,
RAID 1, RAID 0+1, RAID 5 and JBOD), NCQ, AHCI and
Hot Plug functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x COM port header
- 1 x HDMI_SPDIF header
- CPU/Chassis/NB FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 3 x USB 2.0 headers (support 6 USB 2.0 ports)
BIOS Feature - 8Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- NB Voltage Multi-adjustment
- Supports Smart BIOS
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
- ASRock OC Tuner
Unique Feature
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- ASRock AM2 Boost: ASRock Patented Technology
to boost memory performance up to 12.5%
- CPU Temperature Sensing
Hardware Monitor
- Chassis Temperature Sensing
- CPU/Chassis/NB Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS - Microsoft ® Windows
Vista TM / Vista
Certifications - FCC, CE, WHQL
- Quick Installation Guide, Support CD, I/O Shield
Accessories
- ATA 133 Cable
- 2 x SATA Data Cables (Optional)
- 1 x SATA 1 to 1 Power Cable (Optional)
TM II X4 / X3
Ready
®
Vista™ Premium Level HD Audio
® XP / XP Media Center / XP 64-bit /
TM 64-bit compliant
