McIntosh C1100 Service Manual page 36

PARTS LIST
BALANCED I/O PCB 751775 (Cont'd.)
4
Ref. No. Description
R5 RES SMD0805 47.5K 1/8W 1%
R6 RES SMD0805 47.5K 1/8W 1%
R7 RES SMD0805 47.5K 1/8W 1%
R8 RES SMD0805 47.5K 1/8W 1%
R9 RES SMD0805 47.5K 1/8W 1%
R10 RES SMD0805 47.5K 1/8W 1%
R11 RES SMD0805 47.5K 1/8W 1%
R12 RES SMD0805 47.5K 1/8W 1%
R13 RES SMD0805 100K 1/8W 1%
R14 RES SMD0805 100K 1/8W 1%
R15 RES SMD0805 100K 1/8W 1%
R16 RES SMD0805 100K 1/8W 1%
R17 RES SMD0805 100K 1/8W 1%
R18 RES SMD0805 100K 1/8W 1%
R19 RES SMD0805 100K 1/8W 1%
R20 RES SMD0805 100K 1/8W 1%
R21 RES SMD0805 100K 1/8W 1%
R22 RES SMD0805 100K 1/8W 1%
R23 RES SMD0805 100K 1/8W 1%
R24 RES SMD0805 100K 1/8W 1%
LEFT PHONO PCB 751778
5
C1 CAP ELECT 10UF 250V
C2 CAP ELECT 47UF 35V SMD
C3 CAP ELECT 47UF 35V SMD
C5 CAP 47pF 200V 10% NPO SMD0805
C6 CAP MPF 0.01UF 5% 250V
C7 CAP MPF 0.01UF 5% 250V
C8 CAP NPO 1000pF 100V 5% SMD0805
C9 CAP NPO 1000pF 100V 5% SMD0805
C10 CAP MPF 0.0033UF 5% 63VDC
C11 CAP MPF 0.0033UF 5% 63VDC
C12 CAP 10pF 50V 2% SMD0805
C13 CAP 10pF 50V 2% SMD0805
C14 CAP ELECT 10UF 50V SMD
C15 CAP ELECT 10UF 50V SMD
C16 CAP POLYPROP 1uF 20% 250V
C17 CAP POLYPROP 1uF 20% 250V
C18 CAP 220pF 200V 10% NPO SMD0805
C19 CAP 220pF 200V 10% NPO SMD0805
C20 CAP ELECT 47UF 35V SMD
D1 DIODE RECTIFIER 400V 1A SMD
DS1 LED RGB SMD
DS2 LED RGB SMD
DS3 LED RGB SMD
J1 HEADER 2 PIN LATCHING
J2 HEADER 2 PIN LATCHING
J3 CONN 12 PIN FFC
J4 8 PIN 2.5MM SHROUDED
PCB1 PC BD LEFT PHONO TUBE
R1 RES MF 47.5K 1% 1/4W
R2 RES MF 47.5K 1% 1/4W
R3 RES MF 475K 1% 1/4W
R4 RES MF 475K 1% 1/4W
R5 RES MF 953 OHM 1% 1/4W
R6 RES SMD0805 3.92K 1/8W 1%
R7 RES MF 2.21K 1% 1/4W
R8 RES SMD0805 3.92K 1/8W 1%
R9 RES MF 75K 1% 1/4W
(Cont'd.)
Part No.
145013
145013
145013
145013
145013
145013
145013
145013
145014
145014
145014
145014
145014
145014
145014
145014
145014
145014
145014
145014
066558
066604
066604
061368
064472
064472
061391
061391
064455
064455
061405
061405
066602
066602
064433
064433
061369
061369
066604
070208
058209
058209
058209
117766
117766
117907
118046
130287
144526
144526
144604
144604
144661
145027
144584
145027
144552
Ref. No. Description
R10 RES MF 75K 1% 1/4W
R11 RES SMD0805 1M 1/8W 1%
R12 RES SMD0805 1M 1/8W 1%
R13 RES MF 1M 1% 1/4W
R14 RES MF 1M 1% 1/4W
R15 RES MF 475K 1% 1/4W
R16 RES MF 475K 1% 1/4W
R17 RES SMD0805 5.62K 1/8W 1%
R18 RES SMD0805 5.62K 1/8W 1%
R19 RES TF 1K 1% 0.1W SMD0805
R20 RES TF 10 1% 0.1W SMD0805
R21 RES MF 150K 1% 1/4W
R22 RES TF 100K 1% 0.1W SMD0805
R23 RES MF 150K 1% 1/4W
R24 RES TF 100K 1% 0.1W SMD0805
R25 RES TF 1K 1% 0.1W SMD0805
R26 RES TF 1K 1% 0.1W SMD0805
R27 RES SMD0805 15K 1/8W 1%
R28 RES SMD0805 6.81K 1/8W 1%
R29 RES SMD0805 4.75K 1/8W 1%
R30 RES SMD0805 5.62K 1/8W 1%
V1 TUBE 12AX7A SCREENED 165076
(V1) SOCKET TUBE 9 PIN GOLD
V2 TUBE 12AX7A SCREENED 165076
(V2) SOCKET TUBE 9 PIN GOLD
V3 TUBE 12AX7A SCREENED 165076
(V3) SOCKET TUBE 9 PIN GOLD
RIGHT PHONO PCB 751779
6
C1 CAP ELECT 10UF 250V
C2 CAP ELECT 47UF 35V SMD
C3 CAP ELECT 47UF 35V SMD
C4 CAP 47pF 200V 10% NPO SMD0805
C6 CAP MPF 0.01UF 5% 250V
C7 CAP MPF 0.01UF 5% 250V
C8 CAP NPO 1000pF 100V 5% SMD0805
C9 CAP NPO 1000pF 100V 5% SMD0805
C10 CAP MPF 0.0033UF 5% 63VDC
C11 CAP MPF 0.0033UF 5% 63VDC
C12 CAP 10pF 50V 2% SMD0805
C13 CAP 10pF 50V 2% SMD0805
C14 CAP ELECT 10UF 50V SMD
C15 CAP ELECT 10UF 50V SMD
C16 CAP POLYPROP 1uF 20% 250VDC
C17 CAP POLYPROP 1uF 20% 250VDC
C18 CAP 220pF 200V 10% NPO SMD0805
C19 CAP 220pF 200V 10% NPO SMD0805
C20 CAP ELECT 47UF 35V SMD
D1 DIODE RECTIFIER 400V 1A SMD
DS1 LED RGB SMD
DS2 LED RGB SMD
DS3 LED RGB SMD
J1 HEADER 2 PIN LATCHING
J2 HEADER 2 PIN LATCHING
J3 CONN 12 PIN FFC
J4 8 PIN 2.5MM SHROUDED
PCB1 PC BD LEFT RIGHT PHONO TUBE
R1 RES MF 47.5K 1% 1/4W
R2 RES MF 47.5K 1% 1/4W
60
Part No.
144552
145042
145042
144577
144577
144604
144604
145028
145028
145117
145063
144627
145062
144627
145062
145117
145117
145011
145029
145008
145028
165080
178195
165080
178195
165080
178195
066558
066604
066604
061368
064472
064472
061391
061391
064455
064455
061405
061405
066602
066602
064433
064433
061369
061369
066604
070208
058209
058209
058209
117766
117766
117907
118046
130287
144526
144526
