2-SPEED BLENDER
COMMERCIAL
Operating Instruction Manual
Model
Voltage ~ Hz
Power
Amperage
Plug Type
Volume
Overall Height
Weight
15-1/4" (387mm)
Base Dimensions
NEMA
44oz
5.5 lbs
XLB-44
120V ~ 60Hz
400W
3.5A
5-15P
(1.25 L)
(2.5kg)
Width
Depth
Height
6-1/2"
8"
7"
(165mm)
(203mm)
(177mm)
BEFORE OPERATING ANY EQUIPMENT, READ AND FAMILIARIZE YOURSELF WITH THESE USE AND SAFETY INSTRUCTIONS
Congratulations on your purchase of this BAR MAID® commercial blender. When used as intended, and with proper
care and maintenance, you are sure to experience years of reliable operation from this equipment. To ensure best
results, it is important that you read and follow the instructions in this manual carefully. It is important to keep
these instructions in a safe place for future reference.
Advertisement
Table of Contents
Related Manuals for Winco Bar Maid XLB-44
Summary of Contents for Winco Bar Maid XLB-44
-
Page 1: Specifications
2-SPEED BLENDER COMMERCIAL Operating Instruction Manual Model Voltage ~ Hz Power Amperage Plug Type Volume Overall Height Weight 15-1/4" (387mm) Base Dimensions NEMA 44oz 5.5 lbs XLB-44 120V ~ 60Hz 400W 3.5A 5-15P (1.25 L) (2.5kg) Width Depth Height 6-1/2" 8"... -
Page 2: Warnings
L'USINE DEVRA EFFECTUER TOUT L'ENTRETIEN ET LES AND REPAIR. BEFORE DOING ANY MAINTENANCE RÉPARATIONS. AVANT DE FAIRE TOUT ENTRETIEN OU OR REPAIR, FOLLOW SERVICE SET UP RÉPARATION, VEUILLEZ CONTACTER WINCO. ARRANGEMENT ON PAGE 10. Introduction Immediately Inspect for Shipping Damage Congratulations on the purchase of your Bar Maid®... -
Page 3: Table Of Contents
Commercial 2-Speed Blender Commercial 2-Speed Blender Table of Contents Specifications ..................1 Warnings ....................2 Introduction ..................2 Table of Contents ................3 Packaging .................... 3 Important Safeguards ................ 4 Operation .................... 6 Cleaning, Care & Maintenance ............6 Safety & Troubleshooting ..............7 Exploded View .................. -
Page 4: Important Safeguards
5. DO NOT operate this device or any other electrical equipment with a damaged cord or plug, or after the unit malfunctions, is dropped or damaged in any manner. Return to the nearest WINCO Authorized Service Center for examination, repair and/or adjustment. -
Page 5: Operation
Commercial 2-Speed Blender Operation Proper Grounding Mise à la terre correcte USE A GROUNDED OUTLET UTILISER UNE PRISE AVEC MISE À LA TERRE DO NOT ADD AN ADAPTOR TO THE PLUG NE PAS AJOUTER UN ADAPTATEUR SUR LA FICHE This machine is provided with a three-pronged grounding plug. The outlet to Cette machine est équipée d'une fiche à... -
Page 6: Cleaning, Care & Maintenance
DO NOT use a pressure washer to clean. DO NOT wash parts in an automatic dishwasher. NOTE: Proper cleaning instructions must be followed; otherwise, operation of the unit may be seriously impaired. WINCO authorized service personnel must perform any other servicing. ®... -
Page 7: Safety & Troubleshooting
Parts protected by the manufacturer or its agent are not to be adjusted by the installer unless the installer is an authorized service agent. If you have any questions or problems DO NOT send unit to WINCO® without first contacting our customer service department. -
Page 8: Exploded View
Commercial 2-Speed Blender Exploded View MODEL XLB-44... -
Page 9: Parts List
Commercial 2-Speed Blender Parts List MODEL XLB-44 DESCRIPTION Part # Filler Cap XLB44-P1 Container Cover XLB44-P2 Container XLB44-P3 Gasket XLB44-P4 Cutter Assembly XLB44-P5 Collar XLB44-P6 Clutch XLB44-P7 Switch Assembly XLB44-P8 Suction Feet XLB44-P9 Container set (Group 1-6) XLB44-P10 Please contact factory for special order parts not listed. -
Page 10: Limited Warranty
Limited Warranty WINCO® warrants to the original purchaser of new equipment that said equipment, when installed in accordance with our instructions within North America and subjected to normal use, is free from defects in material or workmanship for a period of 1 year. - Page 11 WARRANTY SERVICE THE FOREGOING WARRANTY PROVISIONS ARE A COMPLETE AND EXCLUSIVE STATEMENT BETWEEN THE BUYER AND DO NOT send unit to WINCO® without first contacting our SELLER. WINCO® NEITHER ASSUMES NOR AUTHORIZES customer service department: 973-295-3899. ANY PERSONS TO ASSUME FOR IT ANY OTHER OBLIGATION To initiate warranty service please visit our online portal: OR LIABILITY IN CONNECTION WITH SAID EQUIPMENT.
- Page 12 Model: XLB-44 www.wincous.com...
