Living Spaces CATANIA 326512 Assembly Instructions

PLEASE READ ALL INSTRUCTIONS BEFORE STARTING THE ASSEMBLY OF THIS PRODUCT. THESE PIECES ARE HEAVY.
CAUTION:
IN ORDER TO PREVENT PERSONAL INJURIES AND ENSURE THAT THIS PRODUCT IS NOT DAMAGED DURING THE
ASSEMBLY PROCESS, IT IS STRONGLY RECOMMENED THAT YOU REQUIRE HELP FROM ONE OR MORE PEOPLE.
VEUILLEZ LIRE TOUTES LES INSTRUCTIONS AVANT DE COMMENCER L'ASSEMBLAGE DE CE PRODUIT. LES
ATTENTION:
DIFFÉRENTES PARTIES SONT LOURDES AFIN DE PARER TOUTE BLESSURE ET D'ÉVITER QUE LE PRODUIT NE SUBISSE
DES DOMMAGES. IL EST FORTEMENT RECOMMANDÉ DE DEMANDER DE L'AIDE DE LA PART D'UNE OU PLUSIEURS
PERSONNES DURANT L'ASSEMBLAGE.
FAVOR DELEER TODES LAS INSTRUCCIONNES ANTES DE ENSAMBLAR SU PRODUCTO. ESTAS PIEZAS SON PESADAS.
CUIDADO:
PARA PREVENIR HERIDAS PERSONALES Y ASEGURAR QUE SU PRODUCTO NO SEA DAN ADO MIENTRAS ES
ENSAMBLADO SE RECOMIENDA LA ASISTENCIA DE UNA O MAUS PERSONAS.
B
LIST OF PARTS AND HARDWARE
Description
No.
A
BED FRAME
B FOOTBOARD
C SIDE RAIL RIGHT
D SIDE RAIL LEFT
SUPPORT LEG WITH
E
BOLT ATTACHED HEAD
F
MATTRESS SLAT
G
RAIL LEG LEFT
H
RAIL LEG RIGHT
I
RAIL LEG FRONT
J
CENTER RAIL
K
HEADBOARD
ASSEMBLY INSTRUCTIONS
CATANIA QUEEN PLATFORM BED WITH HEADBOARD
F
D
G
J
I
QUEEN PLATFORM LS SKU # 326512
QUEEN HEADBOARD LS SKU # 326520
C
H
LIST OF PARTS AND HARDWARE
Q'ty No.
1 1
1 2
1 3
1 4
5
4
6
16
7
1
8
1
9
1
10
2
11
1
K
A
E
Description
Dowel
Ø9.6*30
Key M4
Bolt M6*60
Bolt M6*50
Half circle washer
14.5*28*7.3*8
M4*35
Screws
M4*45
Screws
Barrel bolt
M6*13
M8*22
Flat washer
Bolt M8*60
M8*13
Lock washer
Q'ty
27
1
12
14
6
40
4
6
8
8
8
