A
NTENNA
SPECIFICATIONS
Working Environment
XTT901, XTT906, XTT908 .....
XTT902, XTT903, XTT904,
XTT907 ..................................
XTT905 ..................................
XTT909 ..................................
XTT950, XTT951, XTT952 .....
Buzzer
Volume and Tone ...................
Keypad
XTT904 and XTT907 ..............
XTT905 and XTT952 ..............
ImproX 125 kHz Antenna Readers
INSTALLATION MANUAL
XTT901-1-0-GB-XX XTT902-1-0-GB-XX XTT903-1-0-GB-XX
XTT904-1-0-GB-XX XTT905-1-0-GB-XX XTT906-1-0-GB-XX
XTT907-1-0-GB-XX XTT908-1-0-GB-XX XTT909-1-0-GB-XX
XTT950-1-0-GB-XX XTT951-1-0-GB-XX XTT952-1-0-GB-XX
R
EADERS
Designed to work in an indoor or outdoor
environment similar to IP66. The Antenna
Readers are, therefore, sealed (potted) against
water.
Designed to work in an indoor or outdoor
environment similar to IP53. The Antenna
Readers are, therefore, sealed (potted) against
water.
Designed to work in an indoor or protected
outdoor environment similar to IP42. The
Antenna Reader is, therefore, not sealed
against water.
The IP rating for this Antenna Reader is
equivalent to the selected Cabinet's rating.
Designed to work in an indoor or protected
outdoor environment similar to IP54.
NOTE:
Certain plastic Readers (XTT901,
XTT902, XTT905, XTT907,
XTT908, XTT951 and XTT952) are
RoHS compliant and do not contain
any UV stabilizer.
Single tone, 4-step adjustable volume.
NOTE:
The ImproX MMA (XTT901) does
not include a Buzzer.
12 Alphanumeric keys.
12 Numeric keys.
MODEL NUMBER:
Advertisement
Related Manuals for impro technologies ImproX XTT901-1-0-GB Series
Summary of Contents for impro technologies ImproX XTT901-1-0-GB Series
- Page 1 MODEL NUMBER: XTT901-1-0-GB-XX XTT902-1-0-GB-XX XTT903-1-0-GB-XX XTT904-1-0-GB-XX XTT905-1-0-GB-XX XTT906-1-0-GB-XX XTT907-1-0-GB-XX XTT908-1-0-GB-XX XTT909-1-0-GB-XX XTT950-1-0-GB-XX XTT951-1-0-GB-XX XTT952-1-0-GB-XX NTENNA EADERS ImproX 125 kHz Antenna Readers INSTALLATION MANUAL SPECIFICATIONS Working Environment XTT901, XTT906, XTT908 ..Designed to work in an indoor or outdoor environment similar to IP66. The Antenna Readers are, therefore, sealed (potted) against water.
-
Page 2: Installation Information
Status Indicators Status LED ......Bi-coloured Red or Green (externally visible). INSTALLATION INFORMATION Accessories Find the following when unpacking the Antenna Reader: XTT901 to XTT904, XTT907, XTT951 and XTT952 Either an ImproX MMA Antenna Reader (XTT901-1-0-GB-XX) housed in a Dark Grey, ABS Plastic housing. - Page 3 Four Counter-sunk Self-tapping Screws (M2 x 6 mm). An extra Serial Number Label. XTT906 and XTT908 Either an ImproX RA Antenna Reader (XTT906-1-0-GB-XX) housed in PVC sheathing. The ImproX RA includes 8 m (26 ft) of 4-core cable. ...
- Page 4 Distance between Antenna Readers from the SAME Terminal, Controller or Receiver To avoid mutual interference, install the Antenna Readers no closer than 150 mm (6 in) apart. Distance between Antenna Readers from DIFFERENT Terminals, Controllers or Receivers To avoid mutual interference, install the Antenna Readers no closer than 500 mm (20 in) apart.
- Page 5 XTT906 Secure the ImproX RA in the mounting surface, using a suitable filling agent. Figure 1: Mounting the ImproX RA XTT909 WARNING: DO NOT MOUNT THE IMPROX CA IN THE SAME ELECTRICAL JUNCTION BOX AS THE MAINS ELECTRICAL SUPPLY. Figure 2: Electrical Conduit Blanking Plate Options XTT301-0-0-GB-16 September 2011 Page 5...
- Page 6 The ImproX CA is approved for use with the following Electrical Conduit Blanking Plates (specific to the European Market): Jung LS994B. Jung CD500. Merten ARTEC. Gira System 55. Housing the ImproX CA Drill a 5 mm hole in the centre of your chosen Electrical Conduit Blanking Plate, to accommodate the Status LED.
- Page 7 Connecting the ImproX Antenna Readers Figure 3 to Figure 7 show detailed connection diagrams for the Antenna Readers: Figure 3: ImproX Antenna Reader Connected to the IXP220 Controller XTT301-0-0-GB-16 September 2011 Page 7...
- Page 8 Figure 4: ImproX Antenna Reader Connected to the IXP20 Controller XTT301-0-0-GB-16 September 2011 Page 8...
- Page 9 Figure 5: ImproX Antenna Reader Connected to the ImproX iTT XTT301-0-0-GB-16 September 2011 Page 9...
- Page 10 Figure 6: ImproX Antenna Reader Connected to the SupaGate Receiver XTT301-0-0-GB-16 September 2011 Page 10...
- Page 11 Figure 7: ImproX Antenna Reader Connected to the ImproX MfT XTT301-0-0-GB-16 September 2011 Page 11...
-
Page 12: Guarantee Or Warranty
On powering up, the Antenna Reader’s Status LED will illuminate solid Red. NOTE: The Antenna Reader will not read Tags until configured in the Software. Serial Number Label Once the Antenna Reader is installed, sketch a rough site plan. Attach the Antenna Reader’s loose Serial Number Label and the Controller, Terminal or Receiver’s Fixed Address Label, to the sketched site plan in the position of the Antenna Reader.
