M
ULTI
SPECIFICATIONS
CSN Read Capability ...................
Working Environment
MDK901/HRW900
MDR901/HRW901
HRW903/HRW902.........................
HRK900 & HRK901 .......................
Installation
-
DISCIPLINE
R
EADERS
Impro Multi-discipline Readers
INSTALLATION MANUAL
Slim Tags, Omega Tags, Impro Trinary Tags
(1074 and 2074), Philips HITAG™ 1, Philips
HITAG™ 2, HID Tags (H10301, H10302 and
H10304), ISO 15693-2 iClass Tags, ISO
18092 FeliCa Tags and ISO 14443A
MIFARE® Tags.
NOTE:
Designed to work in an indoor or outdoor
environment similar to IP54. These models
are, therefore, sealed (conformal coated)
against water.
Designed to work in an indoor environment
similar to IP20. These models are NOT sealed
against water and should not be exposed to
rain or splashes.
Please consult the instructions under
Installation Information, on page 4.
Blank Space
HRW903-5-0-GB-XX, HRW902-5-0-GB-XX
MDR901-5-0-GB-XX, MDK901-5-0-GB-XX
HRW900-5-0-GB-XX, HRW901-5-0-GB-XX
HRK900-0-5-GB-XX, HRK901-0-5-GB-XX
HID, FeliCa and MIFARE® are
registered trademarks of HID
Global Corporation (an ASSA
ABLOY Group Brand), The Sony
Corporation and Koninklijke Phillips
Electronics N.V. respectively.
MODEL NUMBERs:
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for impro technologies HRW903-5-0-GB Series
Summary of Contents for impro technologies HRW903-5-0-GB Series
-
Page 1: Installation Manual
MODEL NUMBERs: HRW903-5-0-GB-XX, HRW902-5-0-GB-XX MDR901-5-0-GB-XX, MDK901-5-0-GB-XX HRW900-5-0-GB-XX, HRW901-5-0-GB-XX HRK900-0-5-GB-XX, HRK901-0-5-GB-XX ULTI DISCIPLINE EADERS Impro Multi-discipline Readers INSTALLATION MANUAL SPECIFICATIONS CSN Read Capability ....Slim Tags, Omega Tags, Impro Trinary Tags (1074 and 2074), Philips HITAG™ 1, Philips HITAG™ 2, HID Tags (H10301, H10302 and H10304), ISO 15693-2 iClass Tags, ISO 18092 FeliCa Tags and ISO 14443A MIFARE®... - Page 2 Input Voltage Rating ....8 V DC to 14 V DC, polarity sensitive. NOTE: If the Multi-discipline Reader’s Input Voltage rises or falls outside that specified above; the Reader emits a continuous beep sound. The beep sound consists of a 1-second beep followed by a 1-second interbeep pause.
- Page 3 Status Indicators Status LED ......Tri-coloured Red, Green or Amber (Default) (externally visible). Optical Anti-tamper Open Collector Output on Purple Line. (MDR901/HRW900, GND reference on Grey Line. MDK900/HRW901, HRW903/HRW902) ....Mechanical Anti-tamper Open Collector Output on Purple Line. (HRK900, HRK901) ....GND reference on Grey Line.
-
Page 4: Installation Information
INSTALLATION INFORMATION Accessories Find the following when unpacking the Multi-discipline Reader: • Either an Impro (MDR) Multi-discipline Reader (MDR901-5-0-GB-XX/HRW900-5-0- GB-XX) housed in an ABS Plastic and 304 Stainless Steel housing. The Multi- discipline Reader consists of a Front Cover assembly and a Backing Plate (the Backing Plate is attached with a Hexagonal Screw (M3 x 8 mm)). - Page 5 Distance between Multi-discipline Readers To avoid mutual interference, install the Multi-discipline Readers no closer than 500 mm (20 in) apart. Expect a drop in Tag read range where you install Multi- discipline Readers back-to-back (that is on either side of a wall). Mounting the Multi-discipline Readers CAUTION: Make certain that you mount the Readers on a vibration-free...
-
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS Connecting the Multi-discipline Reader Figure 2 to Figure 7 show typical connections for the Multi-discipline Reader. Figure 1: Multi-Discipline Reader connected to the Wiegand Reader Module MDR300-0-0-GB-08 July 2015 Page 6... - Page 7 Figure 2: Multi-discipline Reader Connected to the Impro iTRT MDR300-0-0-GB-08 July 2015 Page 7...
- Page 8 Figure 3: Multi-discipline Reader Connected to the IXP20 Controller MDR300-0-0-GB-08 July 2015 Page 8...
- Page 9 Figure 4: Multi-discipline Reader Connected to the IXP220 Controller MDR300-0-0-GB-08 July 2015 Page 9...
- Page 10 Figure 5: Multi-discipline Reader Connected to the Impro MfT MDR300-0-0-GB-08 July 2015 Page 10...
- Page 11 Figure 6: Multi-discipline Reader Connected to the Impro TA or Impro iTA MDR300-0-0-GB-08 July 2015 Page 11...
- Page 12 Figure 7: Multi-discipline Reader Connected to the Impro RS or Impro RH MDR300-0-0-GB-08 July 2015 Page 12...
- Page 13 Configuring the Tag Frequency Mode The Multi-discipline Readers offer three different Tag Frequency Modes. To select the Tag Frequency Mode, do the following: Power up the Reader. On power up, you have 5 seconds in which to set the Tag Frequency Mode.
- Page 14 Wiegand 26-bit Protocol Key Codes are reported as a 24-bit code consisting of an 8-bit Facility (or Site) Code, and a 16-bit binary representation of the Key Code. The following format is used: • Bit 1 is the even parity over the first 13 bits. •...
- Page 15 Setting the Fixed Length Mode The number of keys to be buffered and the parity option in the Fixed Length Mode is set as follows: Press and hold down key '2' for 3 seconds. The Status LED enters a fast flash Mode and emits a long beep.
-
Page 16: Power-On Self-Test
Setting Single Key 8-bit Burst Mode Press and hold down key '2' until the Reader beeps continuously. Enter ‘018’ and finish by pressing the Hash Key (#). On acceptance of the change, the Status LED will change to Green. If the change is rejected the Status LED will change to Red. Entering a Facility Code A Facility Code only applies when PIN-codes are used. -
Page 17: Guarantee Or Warranty
GUARANTEE OR WARRANTY This product conforms to our Guarantee or Warranty details placed on our Web Site, to read further please go to www.impro.net. CE STATUS Models Status MDK901/HRW900, MDR901/HRW901 User Notes MDR300-0-0-GB-08 July 2015 Page 17... - Page 18 User Notes MDR300-0-0-GB-08 July 2015 Page 18...
- Page 19 User Notes MDR300-0-0-GB-08 July 2015 Page 19...
- Page 20 User Notes This manual is applicable to the Impro Multi-discipline Readers: HRW903-5-0-GB-XX / HRW902-5-0-GB-XX MDR901-5-0-GB-XX / HRW900-5-0-GB-XX, MDK900-5-0-GB-XX / HRW901-5-0-GB-XX, HRK900-0-5-GB-XX, HRK901-0-5-GB-XX. (The last two digits of the Impro stock code indicate the issue status of the product.) Impro MDR\English Manuals\LATEST ISSUE\MDRRdr- MDR300-0-0-GB-07 Issue 08 July 2015...
