1.4 Components of the unit

1 Ground connector
2 Antenna-interfaces
3 USB-interface socket, type USB 3.1
4 USB-interface sockets, type USB 3.2
5 RJ45-interface socket, according PoE++
6 Shielding Box handle with one hand mechanism
1
Illustration 1: Front view MSB-0293
31018.MANUAL / MSB-0293 / V 1.0 / 14 December 2023
2 3 4 5
Page 6 from 13
6
