- Page 1 Install Guide Still Only Countertop Chiller System CR-1SW, CR-1SW-PB & CR-2SW, CR-2SW-PB Register your product online: Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545 03282024...
- Page 2 3/4” inlet and an “ice bank” around the refrigeration Backflow devices should be sourced outlet fittings to a Crysalli CR-1SW or coils and chills the filtered water that from local plumbing stores. CR-2SW still water chiller unit.
- Page 3 CR-1SW & CR-2SW Quick Installation Guide Instructions from the angle stop to the inlet and compressor will automatically 1. Select a location for your chilled of the filter system. Consult turn off when a complete ice bank water dispenser, keeping in mind...
- Page 4 ☐ Air filter in rear of machine is accessible. ☐ All connections leak-free. ☐ Water inlet connection to unit leak free and not pinched off anywhere. ☐ Agitator pump agitating bath water. www.crysalli.com 510.732.0100 Crysalli Beverage Systems a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 5 Using the braided hose in a JG fitting can result in leaks and flooding. To UCM Chiller unit Note: Crysalli does not provide external backflow preventers. Always reference local plumbing codes for the use requirement of a backflow Mount the filter manifold on the preventer, as well as type and location wall with at least 3”...
-
Page 6: Water Inlet Connection
Water Inlet connection CR-1SW and CR-1SW-PB Locate the PP221212W elbow 3/8” hose to tube fitting and a red locking clip. Connect this fitting to the end of 3/8” hose from the filter system and water reg. Then connect this to the water inlet on the chiller. - Page 7 • Safety LED light • Air filter Water Inlet hose connection made with PP221212W elbow swivel fitting and 3/8” hose from the water filter system. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 8 Fill with 6 gallons of water or up to the white stand pipe or up to the white stand pipe CR-UCM2 ice formation around ref coils Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 9 Downward or upward position, quarter turn restricts or slows flow from the faucet. Flow can be completely shut off if turned too far back. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 10 The set screw is the taller notched screw betweenthe two Philips screws for the bracket. Right to tighten and slow the flow. Left to loosen and speed the flow up. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 11 CR-1SW & CR-2SW Countertop Cleaning and Maintenance Recommendations Daily: Quarterly: ☐ Wipe down the unit or draft tower, cleaning and ☐ Check the water bath level, either top off or drying all surfaces. (Use window cleaner on drain, clean and refill.
-
