- Page 1 Install Guide CT Sparkling & Still Countertop Chiller System CR-1, CR-1PB & CR-2, CR-2PB Register your product online: Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545 05132022...
- Page 2 This page is intentionally left blank. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 3 For questions or assistance with install Filter system with 3/4” inlet and outlet contact Crysalli 510-732-0100 or your Water bath must be manaully filled fittings to a Crysalli CR-1 or CR-2 chiller local Distributor. with water. unit. Always reference local plumbing codes...
- Page 4 High Pressure CO2 regulator. over the refrigeration coils to form install. Unbox this regulator and locate a block of ice. On the CR-1 models the 1/4” nylon washer taped to the the ice bank forms along the 3. Locate the CR-24FC water filter packaging.
- Page 5 ☐ CO2 reg connected to CO2 tank (card board/plastic washer used) tight and leak-free. ☐ CO2 tank full, opened all the way and set to 75 PSI. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 6 Condensation will build inside unit & This can take up to 4 hours. must drain or unit will overflow Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 7 Using the braided hose in a JG fitting can result in leaks and flooding. To UCM Chiller unit Note: Crysalli does not provide external backflow preventers. Always reference local plumbing codes for the use requirement of a backflow Mount the filter manifold on the preventer, as well as type and location wall with at least 3”...
-
Page 8: Water Inlet Connection
Water Inlet connection CR-1 and CR-1PB Locate the PP221212W elbow 3/8” hose to tube fitting and a red locking clip. Connect this fitting to the end of 3/8” hose from the filter system and water reg. Then connect this to the water inlet on the chiller. - Page 9 • Safety LED light • Air filter Water Inlet hose connection made with PP221212W elbow swivel fitting and 3/8” hose from the water filter system. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 10 Fill with 4 gallons of water or up to the white stand pipe or up to the white stand pipe CR-UCM2 ice formation around ref coils Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 11 Flow control adjuster X0102 Rear nut fitting Handle: 1/4” barb. Used on Coupling nut holds faucet body 10-2055-90 CR-1, CR-2 and other to shank. Use faucet wrench to countertop models. loosen and tighten. Pivoting handle Adjustable hex fitting nut 10-2220-80...
- Page 12 The set screw is the taller notched screw betweenthe two Philips screws for the bracket. Right to tighten and slow the flow. Left to loosen and speed the flow up. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 13 Tank is empty when needle is in the red zone or zero. Threaded connection to CO2 tank. 1/4” Male flare connection to Pressure adjustment screw and Crysalli chiller. Use nylon washer locking nut. supplied with regulator in fitting. Crysalli Beverage Systems www.crysalli.com 510.732.0100...
- Page 14 CR-1 & CR-2 Countertop Cleaning and Maintenance Recommendations Daily: Quarterly: ☐ Wipe down the unit or draft tower, cleaning and ☐ Check the water bath level, either top off or drying all surfaces. (Use window cleaner on drain, clean and refill.
- Page 15 This page is intentionally left blank. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
-
Page 16: Limited Express Warranty
The obligation of Crysalli under this limited express warranty is limited to the repair or replacement of parts, components, or assemblies that in the opinion of Crysalli are defective. This warranty is further limited to the cost of parts, components or assemblies and standard straight time labor charges at the servicing location. Replacement parts are warranted for 90 days or the balance of the original warranty period, whichever is longer.
