ASROCK G41M-GE3 Specifications

G41M-GE3
Intel G41 + ICH7 Chipsets
®
Product Brief
- Supports FSB1333/1066/800/533 MHz CPUs
- Supports Dual Channel DDR3 1333(OC)
- Intel Graphics Media Accelerator X4500,
®
DirectX 10, Pixel Shader 4.0
- Dual VGA Output: DVI-D and D-Sub ports
- PCIE Gigabit LAN 10/100/1000 Mb/s
- Supports Instant Boot, Instant Flash,
OC Tuner, Intelligent Energy Saver, OC DNA
- ErP/EuP Ready
- 7.1 CH HD Audio (VIA
with QSound)
- Free Bundle : CyberLink DVD Suite - OEM and
Trial; Creative Sound Blaster X-Fi MB - Trial
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
1718S Audio Codec
®
www.as rock.com

Detail Specification

Platform
- Micro ATX Form Factor: 9.6-in x 8.6-in, 24.4 cm x 21.8 cm
CPU
- LGA 775 for Intel
Core 2 Duo / Pentium
TM
/ Celeron , supporting Penryn Quad Core Yorkfield and
®
Dual Core Wolfdale processors
- Supports FSB1333/1066/800/533 MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
Chipset
- Northbridge: Intel
- Southbridge: Intel
- Dual Channel DDR3 memory technology
Memory
- 4 x DDR3 DIMM slots
- Supports DDR3 1333(OC)/1066/800 non-ECC,
un-buffered memory
- Max. capacity of system memory: 8GB
- 1 x PCI Express x16 slot
Expansion Slot
- 1 x PCI Express x1 slot
- 2 x PCI slots
Graphics
- Intel Graphics Media Accelerator X4500
®
- Pixel Shader 4.0, DirectX 10
- Max. shared memory 1759MB
- Dual VGA Output: support DVI-D and D-Sub ports by
independent display controllers
- Supports DVI with max. resolution up to 1920x1200 @
75Hz
- Supports D-Sub with max. resolution up to 2048x1536 @
60Hz
- Supports HDCP function with DVI-D port
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
with DVI-D port
Audio
- 7.1 CH HD Audio (VIA
LAN
- PCIE x 1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
I/O Panel
Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x VGA/D-Sub Port
- 1 x VGA/DVI-D Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
- HD Audio Jack: Side Speaker / Rear Speaker / Central /
Bass / Line in / Front Speaker / Microphone
Connector
- 4 x SATAII 3.0 Gb/s connectors
(No support for RAID and "Hot Plug" functions)
- 1 x ATA100 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x Print port header
- 1 x COM port header
- 1 x TPM header
- 1 x Chassis Intrusion header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
BIOS Feature
- 8Mb AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- Supports I. O. T. (Intelligent Overclocking Technology)
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version),
ASRock Software Suite (CyberLink DVD Suite - OEM
and Trial; Creative Sound Blaster X-Fi MB - Trial)
Unique Feature
- ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
Hardware Monitor
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU Quiet Fan
- CASE OPEN detection
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS
- Microsoft ® Windows
/ XP / XP 64-bit compliant
Certifications
- FCC, CE, WHQL
- ErP/EuP Ready (ErP/EuP ready power supply is required)
Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables (Optional)
Core 2 Extreme / Core 2 Quad /
® TM TM
Dual Core / Celeron Dual Core
® ®
G41
®
ICH7
®
VT1718S Audio Codec)
®
® 7 / 7 64-bit / Vista TM / Vista TM 64-bit
