OPERATION

• Position hands within 10cm of the sensor (Fig. A): hand dryer starts automatically when hands are detected.
• Stops automatically 1 second after hands are removed from the detection zone (Fig. A) or after 1 minute
of continuous use.
• Electrical supply: 1350W, 220-240V~ / 50 - 60Hz.
INSTALLATION
• Electrical supply 220 - 240V~ / 50 - 60Hz class I (with earth).
• The installation must conform to current local regulations in your country.
• IP23 waterproof, electronic control unit
• The hand dryer must be fitted with a differential circuit breaker with 6A protection and 30mA differential.
• The hand dryer must be earthed (Fig. E).
• Unscrew the back screws a (Fig. B), unscrew the 2 side screws b (Fig. B) and remove the cover c (Fig. B).
• Drill 4 holes Ø 8mm (Fig. C).
• Fix the base plate to the wall using screws and rawl plugs (Fig. D) provided. Ensure screws
and rawl plugs are suitable for the type of wall material.
• In the default setting, the hand dryer will deliver hot air. To change to cold air, place the switch (Fig. G) in position 0.
• Replace the cover a (Fig. H) and screw in the 2 side screws b.

ELECTRICAL CONNECTION

• Run the mains power cable type H05RNF-341.5 (not supplied) and screw it to the E, L and N connection plugs
(E = earth connection)
REMEMBER
• Our products must be installed by professional installers according to current regulations and
recommendations in your country, and the specifications of the electrical engineer.
• Avoid splashing the inside the hand dryer mechanism.
• Do not install the hand dryer next to a bath, shower or washbasin.
• Do not shake the hand dryer.
• Do not block the sensor or the air outlet.
• If the hand dryer malfunctions, immediately disconnect the power supply and contact our Technical Support team.
• Do not install the hand dryer outside.
MAINTENANCE & CLEANING
Clean with mild soapy water using a damp cloth.
Do not use scouring powder, abrasive, chlorine, alcohol or acid-based cleaning products.
CLEANING OR REPLACING THE FILTER
Remove the cover (Fig. I). Remove the filter, run under warm water and air dry or replace with a new one. Replace the
filter and refit the cover.
Product conforms to current European Directives.
For the UK market only: Tel. 01491 821 821 - email: technical@delabie.co.uk
For all other markets: Tel. +33 (0)3 22 60 22 74 - email: sav@delabie.fr
After Sales Care Support:
The installation guide is available on: www.delabie.co.uk
The installation guide is available on: www.delabie.com
