- Page 1 INDUSTRIAL ETHERNET SWITCH DIN RAIL MOUNT www.fiberroad.com Quick Start Guide Copyright © 2023 Fiberroad Technology Co., Limited All right reserved.
-
Page 2: Product Overview
Model Support This instruction contains Fiberroad "7" Series Industrial Ethernet Switches, including Thank you for choosing Fiberroad DIN Rail Mount Industrial Ethernet Switch. This but not limited to Unmanaged Industrial Ethernet, Layer 2 Managed Lite Industrial guide is designed to familiarize you with the layout of the Industrial Ethernet Ethernet Switch, Layer 2+ Managed Industrial Ethernet Switch, Layer 2+ Managed Switch and describes how to deploy them in your network. -
Page 3: General Instruction
Power Supply General Instruction Connects the DC power to the switch through the top panel connectors. The switch has a dual-feed DC power supply; two connectors provide primary and secondary DC Panel Layout power (PWR1 and PWR2). The switch power connectors are attached to the switch chassis. -
Page 4: Relay Connection
Relay Connection PoE Power Specification (Based on the model) The relay access terminal is on the top panel of the device. For a two-terminal relay, Spec 802.3af PoE 802.3at PoE+ open circuit state ia s normal non-alarm state; closed state is on when there is any Device Power 12.95W 25.5W... - Page 5 DIP Switch (Unmanaged Series Model, Based on the model) DIP Switch (FR-7A Series) Name State Description Name State Description Enable AI VLAN Broadcast Storm Enable Disable Protection Disable Enable AI EXTEND Disable Function Reserved Enable AI QoS Disable Enable AI PoE Disable Ports and Slots NOTE: Different configuration are available.
- Page 6 100M/1G/2.5G/5G/10G LAN Ports Pinouts NOTE: 1. Power must only be applied in one mode at a time, and this decision is made by the PSE. The PSE can support mode A or B, or both. Typically, the method selected is not a concern for an end-user because it is a requirement of the IEEE 802.3af/at standards that all PDs must support both modes.
- Page 7 Serial Port Specification (Based on the model) LEDs Series Port Parameters LED Name State Description Ports 2 x RS485/422/232 Power is being supplied RS-232: a:TXD, b:RXD, c:Na, d:Na, e: GND (P1&P2) Power is not being Supplied. Signals RS-422: a:T+, b:T-, c:R+, d:R-, e:GND Blinking The system is running well RS:485: a: Na, b:Na, c:D+, d:D-, e:GND...
-
Page 8: Dimension (Unit: Mm)
Dimension (Unit: mm) 2. Support FR-7N, FR-7M, FR-7A Series Unmanaged Industrial Switch and 1. Support FR-7N, FR-7S Series Unmanaged Industrial Switch and Managed Lite Managed and Manage Lite Industrial Switch Industrial Switch... - Page 9 3. Support FR-7N, FR-7M Series, Unmanaged MAX Industrial Switch and 4. Support FR-7N, FR-7M Series, Unmanaged Industrial Switch, and Managed Managed MAX Industrial Switch Industrial Switch PWR1 PWR2 DC9-56V PWR1 PWR2 DC9-56V...
-
Page 10: Environment And Enclosure Guidelines
Before installation, please carefully read these general guidelines: CAUTION: Proper ESD protection is required whenever you handle Fiberroad equipment. Installation and maintenance personnel should be adequately grounded by using ground straps to eliminate the risk of ESD damage to the switch. - Page 11 ❖ Guide for Power Connecting If you are responsible for applying a safety-related programmable electronic system (PES), you need to be aware of the safety equipment in appropriate Tools and Equipment static-safe packaging. Obtain these necessary tools and equipment: ❖ Ratcheting torque flathead screwdriver.
- Page 12 Grounding the Switch Make sure to follow any grounding requirements at your site. Warning: This equipment must be grounded. Never defeat the ground conductor or operate the equipment without a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician if you are uncertain that suitable grounding is available.
-
Page 13: Wiring The Dc Power Source
Connecting the Power Supply to a DC Power Source 7. Tighten the line and neutral terminal block screws. NOTE: Use copper conductors only, rated at a minimum temperature of 167°F NOTE: Torque to 8 in.-lb, not to exceed ten in-lb. (75°C). -
Page 14: Applying Power To The Power Converter
Label Connection Warning: An exposed wire lead from a DC-input power source can conduct harmful V+ Positive DC power connection levels of electricity. Be sure that no exposed portion of the DC-input power source V- Return DC power connection wire extends from the connector(s) or terminal block(s). 4. - Page 15 prevent personal injury resulting from accessibility to live parts. The interior of the Position the rear panel of the switch directly in front of the DIN rail, making enclosure must be accessible only by using a tool. sure that the DIN rail fits in the space between the two hooks near the top of the switch and the spring-loaded latch near the bottom.
-
Page 16: Connecting Alarm Circuits
NOTE: Before screwing the screws onto the wall, make sure that the screw size matches the wall-mounted metal panel CAUTION: Do not stack any equipment on the switc Connecting Alarm Circuits The switch has one alarm output relay circuit for external alarms. The alarm output relay circuit has a normally open and normally closed contact. -
Page 17: Connecting Destination Ports
CAUTION: Do not over-torque the power and alarm connectors’ captive screws. The torque should not exceed two in-lb (0.226 Nm). 6. Repeat Steps 2 through Step 5 to insert the input and output wires of one additional external alarm device into the alarm connector. Connecting Destination Ports These sections provide more information about connecting to the destination ports:... -
Page 18: Installing Sfp Modules Into Sfp Module Slots
For detailed instructions on installing, removing, and cabling the SFP module, see 2. Find the send (TX) and receive (RX) markings that identify the right side of the your SFP module documentation. SFP module. On some SFP modules, the send and receive (TX and RX) markings might be replaced by arrows that show the direction of the connection, either send Warning: Do not insert and remove SFP modules while power is on;... -
Page 19: Connecting To Sfp Modules
3. Insert a dust plug into the optical ports of the SFP module to keep the optical 4. Observe the port status LED: ❖ interfaces clean. The LED turns green when the switch and the target device have an established link. 4. -
Page 20: Express Setup Procedure
Web browser (Microsoft Internet Explorer 11, Firefox 46.01 and 47.0, or b. Switch will automatically reboot ❖ Microsoft Edge 89.0) with JavaScript enabled. (Disable pop-up blockers and 5. Ensure no data port is connected to the switch. proxy settings and ensure that your browser uses the English EN-US language NOTE: pack.) During Express Setup, the switch acts as a DHCP server. -
Page 21: Troubleshooting And Maintenance
13. After you click Submit, these events occur: network. If there is no network connection, troubleshoot the network settings on the computer. a. The switch is configured and exits Express Setup mode. ❖ Make sure that the switch IP address in the browser is correct. b. - Page 22 SFP Module late collision errors might mean a speed or duplex mismatch. Use only Fiberroad SFP modules. Each Fiberroad module has an internal serial EEPROM encoded with security information. A common issue occurs when duplex and speed settings are mismatched between...
- Page 23 The speed parameter adjusts itself even if the connected port The Switch Serial Number does not auto-negotiate. If you contact Fiberroad Technical Assistance or post-sales services, you need to know the serial number of your switch; The serial number is on the bottom. Auto-negotiation and Network Interface Cards...
- Page 24 NOTE: You can use the MDIX auto interface configuration command via CLI or Web conditioning patch cord is required for connection distances greater than 984 GUI to enable the automatic medium-dependent interface crossover (Auto-MDIX) feet (300 m). ❖ feature. When the Auto-MDIX feature is enabled, the switch detects the required 1000BASE-ZX SFP modules can send data up to 62 miles (100 km) using cable type for copper Ethernet and configures the interfaces accordingly.
-
Page 25: Compliance Information
Compliance Information Fiberroad Technology Co., Limited hereby declares that this device is compliance with Directive 2-14/30/EU. A copy of the EU Declaration of conformity is available at https://fiberroad.com/en/resources/certificates/ NOTE: This equipment had been tested and found to comply with the limits for a class digital device, pursuant to part 15 of the FCC Rules.
