Digital Watchdog DWC-MV9WMJ2 Quick Start Manual

Wall mount bracket and junction box for vari-focal vandal dome cameras

Download this manual

Wall mount bracket and junction box for vari-focal

Wall Mount Bracket Mounting Screws and Plastic Anchors (PA4x25mm, head diameter 6.6mm)

Bracket-to-Junction Box Mounting Screws (PM6x12mm, head diameter 12mm)

Neck Connection Screws (PWM3x6mm)

Waterproof Rings for Mounting Screws

Wall Mount Bracket Mounting Template

Junction Box Mounting Screws and Anchors (6.5x38mm, head diameter 12mm, not used)

Camera Mounting screws (PM4x16mm, head diameter 6mm)

Cable Gland Connector

Junction Box Mounting Template (not used)

NOTE:

Download all your support materials and tools in one place.

Go to: http://www.digital-watchdog.com/resources

Search your product by entering the part number in the 'Search by Product' search bar. Results

for applicable part numbers will populate automatically based on the part number you enter.

Click 'Search'. All supported materials, including manuals

and quick start guide (QSGs) will appear in the results.

Tel: +1 (866) 446-3595 / (813) 888-9555

Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday

vandal dome cameras

DWC-MV9WMJ2

WHAT'S IN THE BOX

Quick Start Guide

digital-watchdog.com

Need help?

Do you have a question about the DWC-MV9WMJ2 and is the answer not in the manual?

Page 1 Quick Start Guide Wall mount bracket and junction box for vari-focal vandal dome cameras DWC-MV9WMJ2 WHAT’S IN THE BOX Wall Mount Bracket Mounting Screws and Plastic Anchors (PA4x25mm, head diameter 6.6mm) Bracket-to-Junction Box Mounting Screws (PM6x12mm, head diameter 12mm) Neck Connection Screws (PWM3x6mm)
Page 2 Secure the camera to the mounting bracket using the included camera mounting screws. Adjust the camera’s lens position and angle and place the cover dome on the camera base to complete the installation. Copyright © Digital Watchdog. All rights reserved. Rev: 01/22...
