Digital Watchdog DWC-MV9CMJ Quick Start Manual

Ceiling mount bracket and junction box for fixed lens vandal dome cameras

Ceiling mount bracket and junction box for fixed lens

Ceiling Mount Bracket Mounting Screws and Anchors (6.5x38mm, head diameter 12mm)

Bracket-to-Junction Box Mounting Screws (PM4x12mm, head diameter 8mm)

Neck Connection Screws (PWM3x6mm)

Waterproof Rings for Mounting Screws

Ceiling Mount Bracket Mounting Template

Junction Box Mounting Screws and Anchors (PA4x25mm, head diameter 8mm, not used)

Camera Mounting screws (PM4x16mm, head diameter 8mm)

Cable Gland Connector

NOTE:

Download all your support materials and tools in one place.

Go to: http://www.digital-watchdog.com/resources

Search your product by entering the part number in the 'Search by Product' search bar. Results

for applicable part numbers will populate automatically based on the part number you enter.

Click 'Search'. All supported materials, including manuals

and quick start guide (QSGs) will appear in the results.

Tel: +1 (866) 446-3595 / (813) 888-9555

Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday

vandal dome cameras

DWC-MV9CMJ

WHAT'S IN THE BOX

Quick Start Guide

digital-watchdog.com

Table of Contents

Need help?

Do you have a question about the DWC-MV9CMJ and is the answer not in the manual?

Page 1 Quick Start Guide Ceiling mount bracket and junction box for fixed lens vandal dome cameras DWC-MV9CMJ WHAT’S IN THE BOX Ceiling Mount Bracket Mounting Screws and Anchors (6.5x38mm, head diameter 12mm) Bracket-to-Junction Box Mounting Screws (PM4x12mm, head diameter 8mm) Neck Connection Screws (PWM3x6mm)
Page 2 Secure the camera to the mounting bracket using the included camera mounting screws. Adjust the camera’s lens position and angle and place the cover dome on the camera base to complete the installation. Copyright © Digital Watchdog. All rights reserved. Rev: 12/21...
