State of the art hyper-optimized video management platform designed for ease, speed and efficiency.
DW-BJER4U
DW-BJER2U
Default Login Information for DW Spectrum® IPVMS
Username: admin
E-Rack™
server
Quick start
guide
NOTE: Download all your support materials and tools in one place.
1. Go to: http://www.digital-watchdog.com/support-download/.
2. Search your product by entering the part number in the 'Search by Product' search bar. Results for applicable part
numbers will populate automatically based on the part number you enter.
3. Click 'Search'. All supported materials, including manuals, Quick start guides (QSG), software and firmware will appear in
the results.
Attention: This document is intended to serve as a quick reference for initial setup.
See the DW Spectrum® full manual for more information on features and functionality.
Tel: +1 (866) 446-3595 / (813) 888-9555
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
Blackjack® E-Rack™ — Up to 600Mbps
DW-BJER2U
Password: admin12345
WHAT'S IN THE BOX
Keyboard and
1
mouse
1
Power cable
DW-BJER3U
DW-BJER4U
Default login information for the server's OS
Username: dwuser
1 set
2 set
Quick Start Guide
DW-BJER3U
Password: Dw5pectrum
miniDP to true
HD output
adapter
Rail kit
digital-watchdog.com
1
1 set
