ASROCK AM2NF3-VSTA Specifications

AM2NF3-VSTA
ASRock, an Expert in Windows Vista
Socket AM2 for AMD Athlon
Sempron Processors
Hyper-Transport Technology and AMD Cool 'n' Quiet
Technology
Supports Dual Channel DDRII800/667/533 with 4 DIMM
slots, maximum capacity up to 8GB
1 x AGP8X slot
2 x Serial ATA 1.5Gb/s, support RAID (RAID 0, 1,
JBOD) and "Hot Plug" functions
7.1 channel with Superior Quality Audio
Windows Vista Premium Logo Hardware Ready
TM
Product brief
1. Hyper-Transport Technology and AMD Cool 'n' Quiet Technology
2. Supports Dual Channel DDRII800/667/533 with 4 DIMM slots,
maximum capacity up to 8GB
3. Hybrid Booster - ASRock Safe Overclocking Technology
4. 1 x AGP8X slot
5. 2 x Serial ATA 1.5Gb/s, support RAID (RAID 0, 1, JBOD) and
"Hot Plug" functions
6.
7.1 Channel Superior Quality Audio
7. Windows Vista Premium Logo Hardware Ready
TM
8. ASRock 8CH I/O: 4 x Ready-to-Use USB 2.0 Ports, 7.1 channel
audio jacks
The specification is subject to change without notice. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
64FX / 64X2 / 64 and
TM
Socket AM2 for AMD Athlon 64FX / 64X2 / 64 and Sempron Processors
TM
nVidia NF3 250
R
TM
Detail Specification
- ATX Form Factor: 12.0-in x 8.0-in, 30.5 cm x 20.3 cm
Platform
CPU
- Socket AM2 for AMD Athlon
and Sempron Processors
- Supports AMD's Cool 'n' Quiet Technology
- Supports Untied Overclocking Technology
- Supports Hyper-Transport Technology
Chipset
- nVidia NF3 250
R
Memory
- Dual Channel DDRII memory technology
- 4 x DDRII DIMM slots
- Supports DDRII800/667/533
- Max. capacity: 8GB
- CPU Frequency Stepless Control
Hybrid Booster
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
Expansion Slot
- 5 x PCI slots
- 1 x AGP 8X slot
Graphics N/A
- C-Media CM6501 7.1 channel audio compliant
Audio
with UAA architecture
LAN
- Realtek PHY RTL8201CL
- Speed: 10/100 Ethernet
- Supports Wake-On-LAN
Rear Panel I/O ASRock 8CH I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Port: COM1
- 1 x Parallel Port (ECP/EPP Support)
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 Port
- Audio Jack: Side Speaker/ Rear Speaker/
Central Bass/ Line in/ Front Speaker/ Microphone
Connector - 2 x Serial ATA 1.5 Gb/s connectors, support
RAID (RAID 0, RAID 1, JBOD) and "Hot Plug"
functions
- 2 x ATA133 IDE connectors (support 4 x IDE
devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x Game header
- CPU/Chassis FAN connectors
- 20 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports;
2 of them are shared with USB23 ports on the
I/O panel)
BIOS Feature
- 4Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
Support CD - Drivers, Utilities, AntiVirus Software (Trial Version)
Hardware Monitor - CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
OS
- Microsoft R Windows
Vista compliant
TM
- FCC, CE, WHQL
Certifications
Accessories - Quick Installation Guide, Support CD, I/O Shield
- Floppy/ATA 133 cables
- 1 x SATA data cable (optional)
- 1 x SATA 1 to 1 power cable (optional)
64FX/ 64X2/ 64
TM
R 2000/ XP/ XP 64-bit/
