Dot Hill AssuredSAN 4000 Series Getting Started

Getting Started
Thank you for purchasing a Dot Hill AssuredSAN 4000 Series storage product. This document provides an
overview of product setup tasks and specifies where information to accomplish each task is described in
product documentation. To obtain documentation from the Customer Resource Center (CRC) web site,
browse to crc.dothill.com
Documents.
Product documentation
PDF versions of documents are on the CRC site.
• Product Regulatory Compliance and Safety
• Rackmount Bracket Kit Installation
• Release Notes
• Setup Guide
• RAIDar User Guide
• CLI Reference Guide
• Service Guide
* Printed document also included in product shipkit.
Shipkit contents
If you purchased a controller enclosure, verify that you received the following hardware.
NOTE: Your shipkit may include other cables that otherwise you would need to supply yourself, as shown
in Product setup
Item
Controller enclosure
Enclosure bezel
Power cords
USB cable for the CLI port
If you purchased a drive (expansion) enclosure, verify that you received the following hardware.
Item
Drive enclosure
Enclosure bezel (quantity 1)
Power cords
and select AssuredSAN & R/Evolution Products > product series > Current
*
or 2-Post Rackmount Bracket Kit Installation
on page 2.
Quantity
1
1
2
1
*
Quantity
1
1
2
P/N 83-00005240-10-01 Rev. A, July 2012
*
1
